RCM2228R-A / B
Liquid Crystal Displays
16 characters
脳
2 lines COG module
RCM2228R-A / B
The RCM2228R-A / B is a reflective TN type liquid crystal module with a built-in controller / driver LSI and a display
capacity of 16 characters
脳
2 lines.
Applications
Printers, Copiers, Facsimiles, etc
Features
(1) 5脳7 dot character matrix with cursor.
(2) Interfaces with 4-bit MPUs.
(3) Displays up to 237 characters and special symbols.
(4) Custom character patterns are displayed with the character RAM.
(5) Abundant instruction set including clear display, cursor on/off, and character blinking.
(6) Compact and lightweight for easy assembly to the host instrument.
(7) Operable on single 5V power supply.
(8) Low power consumption.
External dimensions
(Unit : mm) (Viewing direction : 6 : 00)
鹵
5
擄
7.0MAX
0.7鹵0.7
(0.5)
6.0MAX
2
0.7鹵0.7
0.7鹵0.7
1
0.7鹵0.7
1.0MAX.
0.3MAX.
12.4鹵0.3
50.0鹵0.3
(PITCH1.8脳9)16.2鹵0.3
Over-coating regin
10.0鹵0.5
1.5MAX
No.10
No.1
12.0MIN.
9.0MIN.
10.0MAX.
8.0鹵0.3
0.7鹵0.7
12.3鹵0.3
8.7鹵0.7
(0.3)
22.0MAX.
26.0鹵0.3
25.0MAX.
9.4鹵0.2
24.0MIN.
(18.0)
Shield tape
n
tio
ec
dir
:00
6
ing
w
Vie
0.7鹵0.7
2.0MAX.
4.05鹵0.3
41.9鹵0.2
48.0MIN.
1.1鹵0.1
0.7
4.35
0.05
0.5
0.39
2.15
0.05
0.5
Dot de tail
0.7鹵0.7
2.7鹵0.3
1.1鹵0.1
4.0MAX
鹵
5
擄
1/7
