PHOTOMULTlPLlER TUBE
R5496
High Speed Response (Rise Time: 1.5ns, TTS: 0.27ns)
53mm(2 Inch) Diameter, 10鈥搒tage, Bialkali Photocathode, Head鈥揙n Type
GENERAL
Parameter
Spectral Response
Wavelength of Maximum Response
MateriaI
Photocathode
Minimum Effective Area
Window Material
Structure
Dynode
Number of Stages
Base
SuitabIe Socket
Description/Value
300 to 650
420
Bialkali
46
Borosilicate glass
Linear focused
10
19鈥損in glass base
E678鈥?9A (supplied)
Unit
nm
nm
mm dia.
MAXIMUM RATINGS (Absolute Maximum Values)
Supply Voltage
Ambient Temperature
Parameter
Between Anode and Cathode
Between Anode and Last Dynode
Value
3000
1000
鈥?0 to +50
Unit
Vdc
Vdc
擄C
CHARACTERISTlCS (at 25擄C)
Cathode Sensitivity
Anode Sensitivity
Parameter
Luminous (2856K)
Blue (CS 5 58 filter)
Luminous (2856K)
Min.
60
100
Typ.
80
10
1000
800
Max.
Unit
碌A/lm
碌A/lm-b
A/lm
nA
ns
ns
Gain
1.3
脳
1 0
7
Anode Dark Current (after 30min. storage in darkness)
100
1.5
Anode Pulse Rise Time
Time Response
Transit Time Spread (FWHM)
0.27
*Anode characteristics are measured with the voItage distribution ratio shown below.
VOLTAGE DlSTRlBUTlON RATlO AND SUPPLY VOLTAGE
K
G
Dy1
Dy2
Dy3
Dy4
Dy5
Dy6
Dy7
Dy8
Dy9
Dy10
P
Electrodes
Ratio
1.3
4.8
1.2
1.8
1
1
1
1
1
1.5
3
2.5
SuppIy Voltage : 2500Vdc,
K : Cathode, Dy : Dynode, P : Anode, G : Grid
*Acc to be connected to Dy7 (Refer to basing diagram.)
Assembled type is recommended.
