R47320000 Datasheet

  • R47320000

  • KALTGERAETESTECKER IEC GERADE SCHWARZ

  • 2頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

PLUG MATES
Rewireable
NEW
Enhanced designs
now available:
鈥?/div>
For 鈥渃old鈥?connections 70藲C, Protection Class I
鈥?/div>
AC inlet plugs with straight or 90藲 cable entry
鈥?Captive internal contacts for easier
and more reliable wiring
鈥?Cable clamp screw mounts inside the
plug to secure cable
4732.0000
4735.0000
(VDE)
Enhanced 473X Series:
鈥?/div>
Captive internal contacts
鈥?Cable clamp screw mounts inside the plug to secure cable
鈥?Strain reliefs for either harmonized 14 AWG (1.5 mm
2
) or
18 AWG (1.0 mm
2
) cable sizes
鈥?Body material: PPO, UL 94V-0
Contact material: brass, nickel plated
4732 / 4733
UL recognition 10A/250V File #E83589
CSA certification 10A/250V File #LR56242
VDE approval
10A/250V File #83423
4735 / 4736
15A/250V File #E83589
15A/250V File #201904
10A/250V File #124716
4733.0000
4736.0000
4300.0401:
鈥?/div>
Max. wire size 18 AWG (1.0 mm
2
)
鈥?/div>
Disassemble plug for cable connection
鈥?/div>
Material: thermoplastic, UL 94V-O
Prongs and terminals: brass, tin-plated
UL
CSA
SEV
recognition
certification
approval
10A/250V
10A/250V
6A/250V
File #E96454
File #LR70111
File number on request
Standards: EN 60320;
IEC 320/E
4300.0401
4300.0401
4733.0000
4732.0000
20.8
20.8
47.0
81.0
28.7
44.5
28.7
*
70.0
55.5
*
O
7mm for 18 AWG or 1.0 mm
2
O
7mm
for 18 AWG or 1.0 mm
2
4736.0000
4735.0000
21.6
85.5
28.7
44.5
21.6
49.8
28.7
*
70.0
60.0
*
O
8.5mm for 14 AWG or 1.5 mm
2
O
8.5mm for 14 AWG or 1.5 mm
2
Order Numbers
(type)
Inlet plug,
cable entry straight (in plug axis)
4732.0000
4735.0000
Inlet plug,
cable entry angled (90藲 to plug axis)
4733.0000
4736.0000
Inlet plug,
cable entry angled (90藲 to plug axis)
4300.0401
(P685)
Max. cable size
18 AWG or 1.0 mm
2
14 AWG or 1.5 mm
2
22
Schurter, Inc. 鈥?Phone 707-778-6311 鈥?Fax 707-778-6401 鈥?E-mail info@schurterinc.com 鈥?Website http://www.schurterinc.com
