SURFACE MOUNT LED LAMP
PLCC - 2 PACKAGE
PACKAGE DIMENSIONS
0.118 (3.0)
0.102 (2.6)
0.091 (2.3)
0.083 (2.1)
0.083 (2.1)
0.067 (1.7)
.041 (0.1)
0.035 (0.9)
0.028 (0.7)
ORANGE
PURE GREEN
QTLP670C-8
QTLP670C-5
FEATURES
鈥?Non-diffused package excellent for
back-lighting and coupling to light pipe
鈥?Low package profile
0.043 (1.1)
0.020 (0.5)
0.134 (3.4)
0.118 (3.0)
0.094 (2.4)
鈥?Low power dissipation
鈥?Wide viewing angle of 120擄
0.024 (0.6)
0.016 (0.4)
CATHODE
0.007 (.18)
0.005 (.12)
DESCRIPTION
This surface mount lamp is designed with a flat top and sides for
automatic placement equipment. It is compatible with convective
IR and vapor phase reflow soldering and conductive epoxy
attachment process. The package size and configuration conform
to EIA-535 BAAC standard specification for case size 3528 tanta-
lum capacitor.
NOTE:
Dimensions for all drawings are in inches (mm).
ABSOLUTE MAXIMUM RATINGS
Parameter
Operating Temperature
Storage Temperature
Lead Soldering Time - Reflow
Continuous Forward Current
Peak Forward Current
(f = 1.0 KHz, Duty Factor = 1/10)
Reverse Voltage
Power Dissipation
(T
A
= 25擄C unless otherwise specified)
Symbol
T
OPR
T
STG
T
SOL
I
F
I
F
V
R
(I
R
= 10 碌A(chǔ))
P
D
Rating
-40 to +85
-40 to +100
240 for 5 sec
30
160
5
100
Unit
擄C
擄C
擄C
mA
mA
V
mW
ELECTRICAL / OPTICAL CHARACTERISTICS
Part Number
Luminous Intensity (mcd)
Minimum
Typical
Forward Voltage (V)
Maximum
Typical
Peak Wavelength (nm)
Spectral Line Half Width (nm)
Viewing Angle (擄)
2.8
2.0
610
40
120
9
15
QTLP670C-8
ORANGE
(T
A
=25擄C)
QTLP670C-5
PURE GREEN
4
6
I
F
= 20 mA
2.8
2.0
555
30
120
I
F
= 20 mA
I
F
= 20 mA
I
F
= 20 mA
Condition
I
F
= 20 mA
1 of 4
10/26/00
300095A
