SURFACE MOUNT LED LAMP

0603 (0.35 mm Height)

QTLP603C-EB

PACKAGE DIMENSIONS

0.067 (1.7)

0.059 (1.5)

0.035 (0.9)

0.028 (0.7)

Blue

TOP

0.047 (1.2)

0.031 (0.8)

0.016 (0.4)

0.014 (0.35)

SIDE

0.039 (1.0)

CATHODE

BOTTOM

-

POLARITY

NOTE:

+

APPLICATIONS

鈥?Keypad backlighting

鈥?Push-button backlighting

鈥?LCD backlighting

Dimensions for all drawings are in inches (mm).

DESCRIPTION

This surface mount chip LED is designed to 鏗乼 industry standard footprint. Small size, low pro鏗乴e and wide viewing angle make this

LED an ideal choice for backlighting applications and panel illumination. This device utilizes an InGaN/Sapphire blue LED.

FEATURES

鈥?Miniature footprint - 1.6(L) X 0.8(W) X 0.4(H) mm

鈥?Wide viewing angle of 120擄

鈥?Water clear optics

鈥?Moisture-proof packaging

鈥?Available in 0.315" (8mm) width tape on 7" (178mm) diameter reel; 2,000 units per reel

漏 2003 Fairchild Semiconductor Corporation

Page 1 of 6

8/5/03
