QS54/74FCT374T, 2374T
Q
Q
UALITY
S
EMICONDUCTOR,
I
NC.
FEATURES/BENEFITS
High-Speed CMOS
Bus Interface
8-Bit Registers
DESCRIPTION
QS54/74FCT374T
QS54/74FCT2374T
鈥?Pin and function compatible to the 74F374
74FCT374 and 74ABT374
鈥?Industrial temperature 鈥?0擄C to 85擄C
鈥?CMOS power levels: <7.5mW static
鈥?Available in DIP, SOIC, QSOP, ZIP, HQSOP
鈥?Undershoot clamp diodes on all inputs
鈥?TTL-compatible input and output levels
鈥?Ground bounce controlled outputs
鈥?Reduced output swing of 0-3.5V
鈥?Military product compliant to MIL-STD-883,
Class B
FCT-T 374T
鈥?JEDEC-FCT spec compatible
鈥?Std., A, C, and D speed grades with 4.5ns t
PD
for D
鈥?I
OL
= 48mA Ind., 32mA Mil.
FCT-T 2374T
鈥?Built-in 25鈩?series resistor outputs reduce
reflection and other system noise
鈥?Std., A and C speed grades with 5.2ns t
PD
for C
鈥?I
OL
= 12mA Ind.
The QSFCT374T is a high-speed CMOS TTL-
compatible 8-bit buffered registers with a buffered
common clock and a buffered output enable control.
The QSFCT2374T is a 25鈩?resistor output version
useful for driving transmission lines and reducing
system noise. Data is stored in the register on the
rising edge of the clock. The FCT374 is a non-
inverting device. The high output current I
OL
and I
OH
drive high capacitance loads. All inputs have clamp
diodes for undershoot noise suppression. All outputs
have ground bounce suppression (see QSI Applica-
tion Note AN-001), and outputs will not load an active
bus when V
CC
is removed from the device.
om
C
ny
pa
Figure 1. Functional Block Diagram
o
N
an
w
Di
D
Q
25鈩?/div>
Oi
FCT2374
Only
CP
OE
CP
MDSL-00017-04
DECEMBER 28, 1998
QUALITY SEMICONDUCTOR, INC.
1
