Preliminary

QRE2412001

120 Amp/Phase

Powerex, Inc., Hillis Street, Youngwood, Pennsylvania 15697 (724) 925-7272

3 Phase Diode Bridge Module

120 Amp/Phase Up to 2400 Volts

A

E

E

Description:

Powerex 3 Phase Diode Modules are

designed for use in applications

requiring rectification and isolated

packaging. The modules are isolated

for easy mounting with other

components on a common heatsink.

T3

F

C

F

T1

T2

TOP

Features:

n

Electrically Isolated Heatsinking

D

SIDE

n

Metal Baseplate

n

Low Thermal Impedance

for Improved Current Capability

n

UL Recognized

Applications:

T1

T2

T3

n

Battery Supplies

n

Bridge Circuits

n

AC & DC Motor Control

n

Rectifiers

Dimensions

Dimension

A

B

C

D

E

F

GO

/

Note: Dimensions are for reference only.

5.12

1.50

130

38

Inches

Min.

Max.

5.51

Metric

Min.

Max.

140
