QIQ0660001
Powerex Inc., 200 Hillis St., Youngwood, PA 15697 (724) 925-7272
IGBT H-Series Chopper
Hermetic Module
600 Amperes/600 Volts
Description:
Powerex IGBT Hermetic modules are
designed for use in switching applications.
Each Module consists of two IGBT transistors
in a half bridge configuration with each
transistor having a reverse connected super
fast recovery free wheel diode. All
components are located in a hermetically
sealed chamber and are electrically isolated
from the heat sinking base plate, offering
simplified system assembly and thermal
management.
Features:
鈾?/div>
Low Drive Power
鈾?/div>
Low V
CE(sat)
鈾?/div>
Discrete Super-Fast Recovery
(70ns) Free-Wheel Diode
鈾?/div>
Isolated Base plate for Easy Heat
sinking
鈾?/div>
Fully Hermetic Package
鈾?/div>
Package Design Capable of Use at
High Altitudes
鈾?/div>
Package can be modified to adhere
to customer dimensions.
鈾?/div>
D1 sized to match RM400HA
Schematic:
D1
D2
Applications:
鈾?/div>
AC Motor Control
鈾?/div>
Motion/Servo Control
鈾?/div>
Air Craft Applications
Ordering Information:
Contact Powerex Custom Modules
Page 1
PRELIMINARY
06/06/97
