Electronic control gear
QUICKTRONIC廬 for FH lamps, two-lamp version
QT-FH 2x14/230-240
Page 1
N
L
1
2
3
4
5
6
7
L
L
Reference :
Mains voltage [V] :
QT-FH 2x14/230-240
230/240
for lamp :
Permissible voltage fluctuations
[V] :
Lamp start :
Operating frequency [kHz] :
Power factor [c] :
Luminous flux [lm] :
Radio interference suppression :
2x FH 14 W
198 - 254
Permissible battery voltage [V] :
Mains frequency [Hz] :
Mains current [A] :
System wattage [W] :
Temperature range [擄C] :
176 - 254
0/50 - 60
0,13
30,5
-15 - +50
Warm start within 2 s
approx. 40
0,99
2 x 1350
to DIN VDE 0875/CISPR 15/EN
55015
to EN 61547
Harmonics :
to DIN VDE 0712 Part 23/IEC
929/EN 61000-3-2
359
30
20
434742
Immunity :
Length l [mm] :
Height h [mm] :
Standard pack [pcs] :
EAN 40 50300 :
Width b [mm] :
Distance between holes a [mm] :
Weight [g] :
30
350
270
QUICKTRONIC廬 for T5/16 mm diameter fluorescent lamps are electronic high-frequency control gear.
T5/16 mm diameter fluorescent lamps represent a new generation of lighting systems. They combine compact lamp dimensions (16 mm diameter) with slim
ECGs with small cross-sections, giving luminaire manufacturers enormous freedom to design stylish luminaires with excellent directional lighting. T5/16 mm
diameter fluorescent lamps can only be operated with electronic control gear.
There are two system families:
1. QUICKTRONIC廬 QT-FH available in 14W, 21W, 28W and 35W models. Designed for maximum luminous efficacy (104 lm/W).
2. QUICKTRONIC廬 QT-FQ available in 24W, 39W, 54W and 80W models. Designed for maximum luminous flux (up to 7000 lm for FQ 80W).
Comfort:
路 Flicker-free ignition
1
2
