QFCT-5923 Datasheet

  • QFCT-5923

  • MT-RJ Duplex Single Mode Transceiver

  • 12頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Agilent HFCT-5903E MT-RJ Duplex
Single Mode Transceiver
Data Sheet
Description
The HFCT-5903E transceiver is a
high performance, cost effective
module for serial optical data
communications applications
specified for a signal rate of
125 MBd. It is designed to provide
an FDDI SMF-PMD1 link for FDDI
or Fast Ethernet applications and
is also compatible with ATM/
SONET/SDH transceivers. The
HFCT-5903 does not include a nose
shield and is not recommended
due to the potential degradation
of EMI performance in a complete
system. The HFCT-5903 is
available on the rare occasion that
a system mechanical design may
not allow for a nose shield.
This module is designed for single
mode fiber and operates at a
nominal wavelength of 1300 nm.
It incorporates Agilent鈥檚 high
performance, reliable, long
wavelength optical devices and
proven circuit technology to give
long life and consistent service.
The transmitter section uses an
advanced SMQW Fabry Perot
laser with full IEC 825 and CDRH
Class I eye safety.
The receiver section uses a
MOVPE grown planar PIN
photodetector for low dark
current and excellent
responsivity.
A pseudo-ECL logic interface
simplifies interface to external
circuitry.
Features
鈥?MT-RJ duplex single mode
transceiver
鈥?Power compliant to ANSI
X3.184- 1993 standard for FDDI
SMF-PMD category 1
optoelectronic performance
鈥?Single +3.3 V power supply
鈥?Multisourced 2 x 5 pin
configuration
鈥?Interchangeable with LED
multisourced 2 x 5 transceivers
鈥?Unconditionally eye safe
laser IEC 825/CDRH Class 1
compliant
鈥?Temperature range:
0擄C to +70擄C
Applications
鈥?FDDI SMF-PMD1
鈥?Fast ethernet
鈥?ATM compatible
