Hermetically sealed and isolated metal
packages
Applications:
Sonar Driver, Piezo Driver, ATE and
others
Customer specific details:
-
Different hermetically sealed
metal packages available
-
Quiescent current
-
Internal compensation
-
Temperature alarm/shutdown
-
The amplifiers requires an
additional +5V supply for the
control of the shutdown feature.
This supply voltage can be
changed to other values, like
3.3V or 12V.
Documented production to MIL-Standards
available on request. For similar products see:
QA451,QA453
Absolute Maximum Ratings (Shortform):
Max. Operating Voltage V
P
-V
N
(TC under 20擄C: 0.4V/擄C)
Max. Voltage Shutdown-Pin SD to DGND
Max. Input Common Mode Voltage
Max. Input Differential Voltage
Max. DC Ouput Current (in SOA Limits)
WARNING: Amplifier has no built-in current limit!
Max. Cont. Power Dissipation T
C
=25擄C, DC Mode
Max. Power Dissipation Sinewave CW-Mode , T
C
=25擄C,
10kHz<f<100kHz
Max. Pulsed Power Dissipation in Sinewave Burst Mode
T
C
=25擄C, 10kHz<f<250kHz, T
Burst
<10ms, T
Burst
/T
Cycle
鈮?/10
Operating Temperature Range
240V
鹵20V
V
N
鈮?/div>
V
in-
,V
in+
鈮?/div>
V
P
8V
8A
80W
100W
150W
-40擄C鈥?25擄C
1
Quintenz Hybridtechnik
鈥?/div>
www.quintenz.de
鈥?/div>
Fax 0049-89-759 25 45
copyright Quintenz Hybridtechnik 2004
