DLR1414
HIGH EFFICIENCY RED
DLO1414
GREEN
DLG1414
RED
.145" 4-character 5 x 7 Dot Matrix
Alphanumeric Intelligent Display
with Memory/Decoder/Driver
Dimensions in inches (mm)
.0200 (.51)
.1750
(4.45)
.0920
(2.34)
.240
(6.10)
ref.
.012 (.30)
鹵
.002 (.05)
12 pl.
.0220
(.56)
.1440
(3.66)
.700 max.
(17.78)
Luminous
Intensity
Code
.800
(20.32)
max.
.600鹵.020
(15.24鹵.51)
.210
(5.33)
.010 (.25) 4 pl.
.070 (1.78)
鹵
.003 (.08) 4 pl.
.240 (6.10)
Part Number
FEATURES
鈥?Dot Matrix Replacement for DL1414T
鈥?0.145" High, Dot Matrix Character
鈥?128 Special ASCII Characters for English,
German, Italian, Swedish, Danish, and Norwe-
gian Languages
鈥?Wide Viewing Angle: X Axis
鹵
50
擄
, Y Axis
鹵
75
擄
鈥?Close Vertical Row Spacing, 0.800" Centers
鈥?Fast Access Time, 110 ns at 25
擄
C
鈥?Compact Size for Hand Held Equipment
鈥?Built- in Memory
鈥?Built-in Character Generator
鈥?Built-in Multiplex and LED Drive Circuitry
鈥?Direct Access to Each Digit Independently
and Asynchronously
鈥?TTL Compatible, 5 Volt Power
鈥?Low Power Consumption, 20 mA per Charac-
ter Typical
鈥?Intensity Coded for Display Uniformity
鈥?Extended Operating Temperature Range:
鈥?0
擄
C to +85
擄
C
鈥?End Stackable, 4-Character Package
Pin Indicator
.050 (1.27) 4 pl.
DLX 1414
SIEMENS YYWW
Z
.160鹵.020
(4.06鹵.51)
EIA Date Code
.100 (2.54) 10 pl.
at Seating Plane
.018 (.46) 12 pl.
.095 (2.41)
ref.
Tolerance: XXX鹵 .01 (.254)
DESCRIPTION
The DLR/DLO/DLG1414 is a four digit 5x7 dot matrix display module with a
built-in CMOS integrated circuit. This display is a drop-in dot matrix replace-
ment for the DL1414T with segmented characters.
The integrated circuit contains memory, ASCII ROM decoder, multiplex cir-
cuitry and drivers. Data entry is asynchronous and random. A display system
can be built using any number of DLX1414s since each character in any
DLX1414 can be addressed independently and will continue to display the
character last stored until replaced by another.
System interconnection is very straightforward. The least signi鏗乧ant two
address bits (A0, A1) are normally connected to the like named inputs of all
displays in the system. Data lines are connected to all DLX1414s directly
and in parallel as is the write line (WR). The display then will behave as a
write only memory.
The DLX1414 has several features superior to competitive devices. The
character set consists of 128 special ASCII characters for English, German,
Italian, Swedish, Danish, and Norwegian.
See Appnotes 18, 19, 22, and 23 for additional information.
2鈥?
1
2
3
4
5
