GaAlAs-IR-Lumineszenzdiode in SMT-Geh盲use
GaAlAs Infrared Emitter in SMT Package
SFH 421
SFH 426
SFH 421
SFH 426
Wesentliche Merkmale
鈥?GaAIAs-LED mit sehr hohem Wirkungsgrad
鈥?Gute Linearit盲t (I
e
=
f
[
I
F
]) bei hohen Str枚men
鈥?Gleichstrom- (mit Modulation) oder
Impulsbetrieb m枚glich
鈥?Hohe Zuverl盲ssigkeit
鈥?Hohe Impulsbelastbarkeit
鈥?Oberfl盲chenmontage geeignet
鈥?Gegurtet lieferbar
鈥?SFH 421 Geh盲usegleich mit SFH 320
SFH 426 Geh盲usegleich mit SFH 325
鈥?SFH 426: Nur f眉r IR-Reflow-L枚tung geeignet.
Anwendungen
鈥?Miniaturlichtschranken f眉r Gleich- und
Wechsellichtbetrieb, Lochstreifenleser
鈥?Industrieelektronik
鈥?鈥濵essen/Steuern/Regeln鈥?/div>
鈥?Automobiltechnik
鈥?Sensorik
鈥?Alarm- und Sicherungssysteme
鈥?IR-Freiraum眉bertragung
Typ
Type
Bestellnummer
Ordering Code
Features
鈥?Very highly efficient GaAIAs-LED
鈥?Good Linearity (I
e
=
f
[
I
F
]) at high currents
鈥?DC (with modulation) or pulsed operations are
possible
鈥?High reliability
鈥?High pulse handling capability
鈥?Suitable for surface mounting (SMT)
鈥?Available on tape and reel
鈥?SFH 421 same package as SFH 320
SFH 426 same package as SFH 325
鈥?SFH 426: Suitable only for IR-reflow soldering.
Applications
鈥?Miniature photointerrupters
鈥?Industrial electronics
鈥?For drive and control circuits
鈥?Automotive technology
鈥?Sensor technology
鈥?Alarm and safety equipment
鈥?IR free air transmission
Geh盲use
Package
Kathodenkennzeichnung: abgesetzte Ecke
cathode marking: bevelled edge
TOPLED
SIDELED
SFH 421
SFH 426
Q62702-P1055
Q62702-P0331
2000-01-01
1
OPTO SEMICONDUCTORS
