NPN Silicon High-Voltage Transistors
PZTA 42
PZTA 43
q
High breakdown voltage
q
Low collector-emitter saturation voltage
q
Complementary types: PZTA 92, PZTA 93 (PNP)
Type
PZTA 42
PZTA 43
Marking
PZTA 42
PZTA 43
Ordering Code
(tape and reel)
Q62702-Z2035
Q62702-Z2036
Pin Configuration
1
2
3
4
B
C
E
C
Package
1)
SOT-223
Maximum Ratings
Parameter
Collector-emitter voltage
Collector-base voltage
Emitter-base voltage
Collector current
Base current
Total power dissipation,
T
S
= 124 藲C
Junction temperature
Storage temperature range
Thermal Resistance
Junction - ambient
2)
Junction - soldering point
R
th JA
R
th JS
鈮?/div>
72
鈮?/div>
17
Symbol
V
CE0
V
CB0
V
EB0
I
C
I
B
P
tot
T
j
T
stg
Values
PZTA 42
PZTA 43
300
300
200
200
6
500
100
1.5
150
鈥?65 鈥?+ 150
Unit
V
mA
W
藲C
K/W
1)
2)
For detailed information see chapter Package Outlines.
Package mounted on epoxy pcb 40 mm
脳
40 mm
脳
1.5 mm/6 cm
2
Cu.
Semiconductor Group
1
