MOTOROLA
SEMICONDUCTOR TECHNICAL DATA
Order this document
by PZTA14T1/D
NPN Small Signal
Darlington Transistor
This NPN small signal darlington transistor is designed for use in switching
applications, such as print hammer, relay, solenoid and lamp drivers. The
device is housed in the SOT-223 package, which is designed for medium power
surface mount applications.
鈥?/div>
High fT : 125 MHz Minimum
鈥?/div>
The SOT-223 Package can be soldered using wave or reflow.
鈥?/div>
SOT-223 package ensures level mounting, resulting in improved thermal
conduction, and allows visual inspection of soldered joints. The formed
leads absorb thermal stress during soldering, eliminating the possibility of
damage to the die.
鈥?/div>
Available in 12 mm Tape and Reel
Use PZTA14T1 to order the 7 inch/1000 unit reel
Use PZTA14T3 to order the 13 inch/4000 unit reel
鈥?/div>
The PNP Complement is PZTA64T1
COLLECTOR 2, 4
PZTA14T1
Motorola Preferred Device
SOT鈥?23 PACKAGE
MEDIUM POWER
NPN SILICON
DARLINGTON
TRANSISTOR
SURFACE MOUNT
4
1
BASE
1
2
3
EMITTER 3
CASE 318E-04, STYLE 1
TO-261AA
MAXIMUM RATINGS
(TC = 25擄C unless otherwise noted)
Rating
Collector-Emitter Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current
Total Power Dissipation @ TA = 25擄C(1)
Operating and Storage Temperature Range
Symbol
VCES
VCEO
VEBO
IC
PD
TJ, Tstg
Value
30
30
10
300
1.5
鈥?65 to 150
Unit
Vdc
Vdc
Vdc
mAdc
Watts
擄C
DEVICE MARKING
P1N
THERMAL CHARACTERISTICS
Thermal Resistance
Junction-to-Ambient (surface mounted)
Maximum Temperature for Soldering Purposes
Time in Solder Bath
R
胃JA
TL
83.3
260
10
擄C/W
擄C
Sec
1. Device mounted on a FR-4 glass epoxy printed circuit board 1.575 in. x 1.575 in. x 0.0625 in.; mounting pad for the collector lead = 0.93 sq. in.
Thermal Clad is a trademark of the Bergquist Company
Preferred
devices are Motorola recommended choices for future use and best overall value.
REV 1
Motorola Small鈥揝ignal
漏
Motorola, Inc. 1996
Transistors, FETs and Diodes Device Data
1
