PTN3331
High speed differential line driver
Rev. 01 鈥?06 August 2002
Product data
1. Description
The PTN3331 is a differential line driver that implements the electrical characteristics
of Low-Voltage Differential Signaling (LVDS) that meets or exceeds the requirements
of the ANSI
TIA/EIA-644 Standard.
LVDS is used to achieve higher data rates on
commonly used media. LVDS overcomes the limitations of achievable slew rates and
EMI restrictions of previous differential signaling techniques. The PTN3331 operates
at 3.3 volt supply levels and current mode output drivers. The output drivers will
deliver a minimum of 247 mV into a 100
鈩?/div>
load when enabled.
The intended application of this device is for point-to-point baseband transmission
rates over a controlled impedance media of approximately 100
鈩?
The maximum rate
and distance of data transfer is dependent upon the attenuation characteristics of the
media selected and the noise coupling to the environment.
The PTN3331 is designed to function over the full industrial temperature range of
鈭?0 擄C
to +85
擄C.
2. Features
s
Meets or exceeds the requirements of ANSI
TIA/EIA-644 Standard
s
Low-Voltage Differential Signaling with output voltage of 350 mV across a 100
鈩?/div>
load
s
300 ps maximum channel to channel output skew
s
500 ps typical output voltage rise and fall times
s
Power dissipation of 100 mW typical at 200 MHz
s
Driver at high impedance when disabled or with V
CC
= 0 V
s
5 volt tolerant inputs with Low Voltage TTL (LVTTL) logic input levels
s
Pin-compatible with AM26LS31 and SN65LVDS31.
3. Applications
s
Low voltage, low EMI, high speed differential signaling
s
Point-to-point high speed data transmission
s
High performance switches and routers.
