PTH03020W Datasheet

  • PTH03020W

  • 22 A. 3.3-V Input Wide-Output Adjust Plug-in Power Module

  • 8頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

PTH03020 Series 鈥?.3-V Input
22-A, 3.3-V Input Non-Isolated
Wide-Output Adjust Power Module
SLTS206A 鈥?MAY 2003 鈥?REVISED MAY 2003
Features
鈥?/div>
Up to 22-A Output Current
鈥?/div>
3.3-V Input Voltage
鈥?/div>
Wide-Output Voltage Adjust
(0.8 V to 2.5 V)
鈥?/div>
Efficiencies up to 93 %
鈥?/div>
120 W/in魯 Power Density
鈥?/div>
On/Off Inhibit
鈥?/div>
Output Voltage Sense
鈥?/div>
Pre-Bias Startup
鈥?/div>
Margin Up/Down Controls
鈥?/div>
Auto-Track鈩?Sequencing
鈥?/div>
Under-Voltage Lockout
鈥?/div>
Output Over-Current Protection
(Non-Latching, Auto-Reset)
鈥?/div>
Over-T
emperature Protection
鈥?/div>
Surface Mountable
鈥?/div>
Operating Temp: 鈥?0 to +85 擄C
鈥?/div>
DSP Compatible Output Voltages
鈥?/div>
IPC Lead Free 2
NOMINAL SIZE =
1.5 in x 0.87 in
(38,1 mm x 22,1 mm)
Description
The PTH03020 series of non-isolated
power modules offers OEM designers a
combination of high performance, small
footprint, and industry leading features.
As part of a new class of power modules
these products provide designers with the
flexibility to power the most complex
multi-processor digital systems using
off-the-shelf catalog parts.
The series employs double-sided surface
mount construction and provides high-
performance step-down power conversion
for up to 22 A of output current from a
3.3-V input bus voltage. The output volt-
age of the PTH03020W can be set to
any value over the range, 0.8 V to 2.5 V,
using a single resistor.
This series includes Auto-Track鈩?
Auto-Track simplifies the task of supply
voltage sequencing in a power system by
enabling modules to track each other, or
any external voltage, during power up and
power down.
Other operating features include an
on/off inhibit, output voltage adjust (trim),
and margin up/down controls. To ensure
tight load regulation, an output voltage
sense is also provided. A non-latching
over-current trip and over-tempterature
shutdown provide load fault protection.
Target applications include complex
multi-voltage, multi-processor systems
that incorporate the industry鈥檚 high-speed
DSPs, micro-processors and bus drivers.
Pin Configuration
Pin
1
2
3
4
5
6
7
8
9
10
Function
GND
V
in
Inhibit *
V
o
Adjust
V
o
Sense
V
out
GND
Track
Margin Down *
Margin Up *
ADVANCE INFORMATION
* Denotes negative logic:
Open
= Normal operation
Ground = Function active
聶
Track
Auto- ncing
e
Sequ
Standard Application
R
set
= Resistor to set the desired ooutput
voltage (see spec. table for values).
Cin = Required electrolytic 1,000 碌F
Cout = Recommended 330 碌F electrolytic
10
1
9
8
7
Track
Margin Down
Margin Up
V
IN
PTH03020W
(Top View)
2
6
V
OUT
3
4
5
V
o
Sense
L
O
A
D
Inhibit
R
SET
0.5 %, 0.1 W
(Required)
GND
For technical support and more information, see inside back cover or visit www.ti.com
+
+
C
IN
1,000 碌F
(Required)
C
OUT
330 碌F
(Optional)
GND
