PTC-01 Datasheet

  • PTC-01

  • PTC-01 Programmer for Melexis PTC Devices

  • 9頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

PTC-01
Programmer for Melexis PTC Devices
Features and Benefits
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
RS-232 serial interface
16-bit voltage measurement
12-bit voltage adjustment
Compact design
Internal or external supply voltage
4 lead SIP (50mil)
RJ45 External Connector
High-level functions in firmware
Applications
鈥?/div>
鈥?/div>
Lab and prototype use
Production use
Ordering Information
Part No.
PTC-01
PTC-SA35 (included)
Description
Programmer Unit
1A 24VDC supply (auto, 100-240VAC 50/60Hz)
Accessories
PTC01 software (for windows NT, 95, and later)
MLX90215 Development Kit
Functional Diagram
Description
The PTC-01 programmer was designed for efficient
and precise calibration of the Melexis family of
programmable ICs. The programmer is designed
to be easily adapted to a standard PC to allow
calibration of programmable sensor ICs within the
operating environment. The PTC-01 programmer
contains its own programmable power supply and
measurement circuitry. The programmer is similar
to a standard EEPROM programmer, but adds
special features such as 16 bit voltage and current
measurement capability, and a configuration
options that will accommodate users from the
prototyping phase directly into production. An IBM
compatible PC is required (not included) to load
software to the programmer and control the
functions of the programmer. DOS and Windows
platforms are available, as well as source code and
firmware. Communication is done through a
standard RS-232 null modem cable to a COM port
of the PC. The PC requires no custom
configuration, allowing the programmer to be used
with any PC with a COM port speed of 19.2kbs or
better.
PTC-01 Programmer
Rev 2.0
15/Nov/2001
Page 1

PTC-01 產品屬性

  • 1

  • 編程器，開發系統

  • 過時/停產零件編號

  • -

  • QuickWriter

  • PTC 設備

  • 帶可編程電源的編程器、串行接口等
