PTB20228 Datasheet

  • PTB20228

  • 6.5 Watts, 1.62-1.66 GHz RF Power Transistor

  • 450.76KB

  • 3頁

  • ERICSSON

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

e
PTB 20228
6.5 Watts, 1.62鈥?.66 GHz
RF Power Transistor
Description
The 20228 is a class AB, NPN, common emitter RF power transistor
intended for 26 Vdc operation from 1.626 to 1.661 GHz. Rated at 6
watts minimum output power, it may be used for both CW and PEP
applications. Ion implantation, nitride surface passivation and gold
metallization are used to ensure excellent device reliability. 100% lot
traceability is standard.
聲
聲
聲
聲
聲
聲
聲
6.5 Watts, 1.62鈥?.66 GHz
Class AB Characteristics
40% Collector Efficiency at 6.5 Watts
Surface Mountable
Available in Tape and Reel
Gold Metallization
Silicon Nitride Passivated
Typical Power Out and Efficiency vs. Power In
10
8
80
64
48
Output Power (Watts)
6
4
2
0
0.0
0.2
0.4
0.6
0.8
1.0
1.2
Efficiency (%)
202
28
LO
TC
OD
E
V
CC
= 26 V
I
CQ
= 40 mA
f = 1.661 GHz
32
16
0
Input Power (Watts)
Package 20227
Maximum Ratings
Parameter
Collector-Emitter Voltage
Collector-Base Voltage
Emitter-Base Voltage (collector open)
Collector Current (continuous)
Total Device Dissipation at Tflange = 25擄C
Above 25擄C derate by
Storage Temperature Range
Thermal Resistance (Tflange = 70擄C)
T
STG
R
胃JC
Symbol
V
CER
V
CBO
V
EBO
I
C
P
D
Value
50
50
4.0
1.0
19.7
0.112
鈥?0 to +150
8.9
Unit
Vdc
Vdc
Vdc
Adc
Watts
W/擄C
擄C
擄C/W
1
9/28/98
