Princeton Technology Corp.
MP3, AAC Decoder IC
Tel : 886-2-29162151
Fax: 886-2-29174598
URL:
http://www.princeton.com.tw
Preliminary Reference
PT8402
Description
The PT8402 is a single chip MPEG audio decoder capable of decoding all layers of compressed elementary
streams, as specified in MPEG 1 and MPEG 2 ISO standards, including the so-called MP3. Another decoding
function that PT8402 supports is AAC (Advance Audio Coding.).
In additional to decoding function, this chip also includes a high-performance D/A converter and headphone driver,
so the user can eliminate the need of external DAC and output circuit.
With external A/D converter, it can also compress incoming signal by using ADPCM algorithm, therefore it can
also playback ADPCM bitstream.
Features
摟
摟
摟
摟
摟
摟
摟
摟
摟
摟
Supports all the Sampling Frequency of MPEG1 (32/44.1/48KHz) and MPEG2(16/22.05/24KHz).
Supports AAC ADTS, ADIF Bitstream.
Serial Bit Stream Input Interface
I
2
S/Normal Audio Data Output Format delivered via a Serial Bus
Power Saving Mode Support
DAC Master Clock (256*fs / 384*fs for 16 / 24 bit DAC) is supported
Built-in Volume and Digital Equalizer Control
Bass Booster, 3D Sound.
Low Operating Voltage, 2.5V.
100-pin, LQFP Package
Applications
摟
摟
摟
摟
Portable MP3 Player
PDA
CD/MP3 player
All other MP3 applications.
PT8402 pre 1.0
Page 1
Updated November 2001
