Princeton Technology Corp
.
Infrared Remote Control Transmitter
DESCRIPTION
Tel : 886-2-29162151
Fax : 886-2-29174598
URL:
http://www.princeton.com.tw
PT2213
PT2213 is a remote control transmitter utilizing CMOS Technology specially designed for
infrared remote control applications. PT2213 can support up to 64 function keys and provides 2
different kinds of system codes. Pin assignments and application circuit are optimized for easy
PCB Layout and low cost advantage.
FEATURES
!
!
!
!
!
!
!
!
!
!
CMOS Technology
Low Power Consumption
Least External Components
Low Voltage Operation
Double Key Operation is provided when SEL2 is connected to VDD.
Up to 64 Function Keys provided
2 Kinds of System Codes
High Efficiency Transmission
Transmission Indication Output Pin provided
Available in 24 Pins, SO or DIP Package
APPLICATIONS
!
!
!
!
!
!
Television
VCR
Video Disc
CD Player
AV Controller
Audio Equipment
PT2213 v1.2
Page 1
Written August 1999
