P
The INCA-IP is the newest member of Infineon's
advanced telephony family of products for digital
telephones. This single-chip solution is cost-
optimized for VoIP terminals featuring conferenc-
ing and hands-free functionality with high-quality
audio performance. The INCA-IP offers advanced
features such as integrated voice codecs, con-
ferencing functionality, advanced echo-cancella-
tion, as well as a full-featured telephony analog
front end (AFE). These voice features are com-
plemented by a full-fledged 3-port Ethernet
switch with packet prioritization for Quality of
Service.
Additional features include an integrated switch,
10/100BaseT Ethernet PHYs, support for power
over LAN, AFE, and DSP. The INCA-IP also offers
advanced security and supports the DES/3DES/
AES standards.
Designed for terminal systems with microphone,
loudspeaker, handset and headset inputs, the
INCA-IP offers a comprehensive single-chip IP
telephony solution.
RODUCT
B
RIEF
Applications
鈻?/div>
CPU Features
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
INCA-IP
鈻?/div>
VoIP Telephone
Voice coding supports G.711,
G.723.1, G729A/B, and G.722
standards
Advanced voice capabilities with
full duplex hands-free functions,
including noise suppression and
Acoustic and Handset Echo
Suppression
Silence compression (transmit)
Voice Activity Detection (transmit)
Comfort noise generation
(receive)
Speech Recognition
Tone Generation for ringing and
DTMF
3-party conferencing with trans-
coding
Integrated Analog front end with
100 mW driver for external
speaker
100 MHz OAK subsystem with
116 Kbytes RAM and 108 Kbytes
ROM
Voice Processing DSP Features
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
Powerful 150 MHz MIPS32鈩?/div>
4Kc鈩?RISC CPU
Hardware accelerator for encryp-
tion (DES/3DES/AES standards)
SDRAM and cache controller
Separate I-Cache and D-Cache
integrated on chip
MMU with 16 entry TLB
5-channel DMA controller
Clock generation unit and power
management
Class of Service determined by
frame VLAN tag or TOS field
鈻?/div>
Configurable output scheduling
mechanism for Quality of Service
Supports 16 VLAN multicast
groups
鈻?/div>
Interfaces / Ports
鈻?/div>
Keypad up to 91 keys can be
directly connected
EJTAG, PCM/IOM-2, GPIO
2x SSC supports SSI, SPI
Asynchronous Serial Interface
Controller
RMII interface for external
transceiver
PWM1 and PWM2
鈻?/div>
鈻?/div>
Ethernet MAC and PHY Features
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
Two 10/100BaseT Ethernet ports
with integrated MAC and PHY
Wire speed Ethernet switch with
embedded packet buffer and
MAC address table
Fully IEEE 802.1Q and IEEE
802.1p compliant
IEEE 802.3x full and half-duplex
flow-control compliant
Supports full 4kByte range of
VLAN IDs
鈻?/div>
鈻?/div>
Software
鈻?/div>
An extensive software support
package is supplied with the
EASY 21553 INCA-IP Evaluation
system
INCA-IP
VoIP System on a Chip
PSB 21553 E
N e v e r
s t o p
t h i n k i n g .
