PS21563
Powerex, Inc., 200 E. Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Intellimod鈩?Module
Dual-In-Line Intelligent
Power Module
10 Amperes/600 Volts
A
D
G
J
DUMMY
PINS
28 27 26 25 24 23 22 21 20 19 18 17 16
29
30
15 14 13
12 11 10
9 8 7
6 5 4
3 2 1
H
K
L
Q
R
C
HEATSINK
SIDE
M
E
E
E
F
F
N
35
34
33
32
31
P
35隆
B
P
S
AA DEEP
(5 PLACES)
V
X
Y
Z
AB
(2 PLACES)
W
H
Q
U
T
TERMINAL CODE
1 V
UFS
2 NC
3 V
UFB
4 V
P1
5 NC
6 U
P
7 V
VFS
8 NC
9 V
VFB
10 V
P1
11 NC
12 V
P
13 V
WFS
14 NC
15 V
WFB
16 V
P1
17 NC
18 W
P
19 NC
20 V
NO
21 U
N
22 V
N
23 W
N
24 F
O
25 C
FO
26 C
IN
27 V
NC
28 V
N1
29 NC
30 NC
31 P
32 U
33 V
34 W
35 N
Description:
DIP and Mini DIP-IPMs are
intelligent power modules that
integrate power devices, drivers,
and protection circuitry in an ultra
compact dual-in-line transfer-mold
package for use in driving small
three phase motors. Use of 5th
generation IGBTs, DIP packaging,
and application specific HVICs
allow the designer to reduce
inverter size and overall design
time.
Features:
鈻?/div>
Compact Packages
Outline Drawing and Circuit Diagram
Dimensions
A
B
C
D
E
F
G
H
J
K
L
M
N
Inches
1.93
1.20
0.20
1.82
0.25
0.32
0.14
0.04
0.07
0.02
0.06
0.07 Min.
0.30
Millimeters
49.0
30.5
5.0
46.23
6.25
8.0
3.556
1.0
1.778
0.5
1.5
1.8 Min.
0.75
Dimensions
P
Q
R
S
T
U
V
W
X
Y
Z
AA
AB
Inches
0.69
0.02
0.41
0.05
0.05
0.10
0.30
0.16 Min.
1.20
1.61
1.65
0.08 Dia.
0.13 Dia.
Millimeters
17.4
0.5
10.5
1.2
1.25
2.5
7.62
4.0 Min.
30.48
41.0
42.0
2.0 Dia.
3.3 Dia.
鈻?/div>
Single Power Supply
鈻?/div>
Integrated HVICs
鈻?/div>
Direct Connection to CPU
Applications:
鈻?/div>
Washing Machines
鈻?/div>
Refrigerators
鈻?/div>
Air Conditioners
鈻?/div>
Small Servo Motors
鈻?/div>
Small Motor Control
Ordering Information:
PS21563 is a 600V, 10 Ampere
Mini DIP Intelligent Power
Module.
1
