PS11034
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Intellimod鈩?Module
Application Specific IPM
15 Amperes/600 Volts
A
D
E
F
G
U
W
1
2
3 4
5 6
7
8
9
10 12 14 16
11 13 15
X
C
(S)
B J K L
AA
M
21
22
23
24
25
26
27
28
29
30
T
BB
S
V
Tc
N
Q
(R)
P
CC
U
Y
Z
X
DD
FF
EE
DD
TERMINAL CODE
1 CBU+
2 CBU-
3 CBV+
4 CBV-
5 CBW+
6 CBW-
7 VD
8 UP
9 VP
10 WP
11 UN
12 VN
13 WN
14 FO
15 V
AMP
16 GND
21 P
1
22 R
23 S
24 T
25 N
1
26 P
2
27 U
28 V
29 W
30 N
2
Description:
Powerex Application Specific IPMs
(ASIPMs) are inteligent power
modules that integrate power
devices, gate drive and protection
circuitry in a compact package for
use in small inverter applications
up to 20kHz. Use of application
specific HVICs allow the designer
to reduce inverter size and overall
design time.
Features:
鈻?/div>
Compact Packages
鈻?/div>
3Phase Converter Bridge
Built-in
Outline Drawing and Circuit Diagram
Dimensions
A
B
C
D
E
F
G
H
J
K
L
M
N
P
Q
Inches
2.91鹵0.04
2.48鹵0.04
0.34鹵0.02
2.36
1.42
0.16
0.02
0.08
0.98
0.59
0.35
0.18
0.20
0.05
1.80
Millimeters
74.0鹵1.0
63.0鹵1.0
8.5鹵0.5
60.0
36.0
4.0
0.6
2.0
25.0
15.0
9.0
4.5
5.08
1.2
45.72
Dimensions
R
S
T
U
V
W
X
Y
Z
AA
BB
CC
DD
EE
FF
Inches
2.72
1.01
2.00鹵0.03
0.16
1.58
0.02
0.65鹵0.02
0.02
0.12鹵0.02
0.18 Rad.
0.09 Rad.
0.12 Rad.
0.8
2.19
0.114
Millimeters
69.0
25.7
50.7鹵0.8
4.0
40.0
0.4
16.5鹵0.5
0.6
3.0鹵0.5
4.5 Rad.
2.25 Rad.
3.0 Rad.
2.0
55.5
3.5
鈻?/div>
Integrated HVICs
鈻?/div>
Direct Connection to DSP/CPU
Applications:
鈻?/div>
Small Motor Control
鈻?/div>
Small Servo Motors
鈻?/div>
General Purpose Inverters
鈻?/div>
Pump and HVAC Motor Control
Ordering Information:
PS11034 is a 600V, 15 Ampere
Application Specific
Intellegent Power Module.
1
PS11034 產品屬性
3
半導體模塊
功率驅動器
Intellimod™
IGBT
3 相橋
15A
600V
2500VDC
30-DIP 模塊
