MITSUBISHI INTELLIGENT POWER MODULES

PM400HSA120

FLAT-BASE TYPE

INSULATED PACKAGE

A

C

N

E

F

N

R-DIA.(4 Typ.)

S

U-DIA.(2 Typ.)

B D

J

T-(4 Typ.)

12345

5. FO

4. VC

3. CI

2. SR

1. V1

E

0.64 MM SQ. PIN (5 Typ.)

C

P-THD.(2 Typ.)

K

L

M

Q

G

LABEL

H

V

1

1

C

Rref

Vcc

Description:

Mitsubishi Intelligent Power Mod-

ules are isolated base modules de-

signed for power switching applica-

tions operating at frequencies to

20kHz. Built-in control circuits pro-

vide optimum gate drive and pro-

tection for the IGBT and free-wheel

diode power devices.

Features:

Complete Output Power

Circuit

Gate Drive Circuit

Protection Logic

鈥?Short Circuit

鈥?Over Current

鈥?Over Temperature

鈥?Under Voltage

Applications:

Inverters

UPS

Motion/Servo Control

Power Supplies

Ordering Information:

Example: Select the complete

part number from the table below

-i.e. PM400HSA120 is a 1200V,

400 Ampere Intelligent Power Mod-

ule.

Type

PM

Current Rating

Amperes

400

V

CES

Volts (x 10)

120

F

O

5

Rfo

TEMP

FO

OUT1

AMP

Rg

Th

S

R

2

SR

OUT2

SENS

C

I

3

Ci

V

C

4

IN

SINK

GND

E

Outline Drawing and Circuit Diagram

Dimensions

A

B

C

D

E

F

G

H

J

K

Inches

3.86

3.46

3.15鹵0.01

2.76鹵0.01

2.56

1.57

Millimeters

98.0

88.0

80.0鹵0.25

70.0鹵0.25

65.0

40.0

Dimensions

L

M

N

P

Q

R

S

T

U

Inches

0.63

0.59

0.35

Metric M8

0.28

0.26 Dia.

0.10

0.100

0.08 Dia.

Millimeters

16.0

15.0

9.0

M8

7.0

Dia. 6.5

2.5

2.54

2.0 Dia.

1.34 +0.04/-0.02 34.0 +1.0/-0.5

1.16

0.79

0.71

29.5

20.0

18.0

Sep.1998
