PM300DSA120
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Intellimod鈩?Module
Single Phase
IGBT Inverter Output
300 Amperes/1200 Volts
A
B
H
H
J
T - DIA.
(2 TYP.)
N SIDE
1. VN1
2. SNR
3. CN1
4. VNC
5. FNO
P SIDE
1. VP1
2. SPR
3. CP1
4. VPC
5. FPO
C2E1
E2
C1
N
1234 5
C
D
P
123 4 5
N
S - (8 TYP.)
E
K
R - DIA.
(4 TYP.)
P - M8 THD.
(3 TYP.)
0.64 MM SQ. PIN
(10 TYP.)
L
F G
Q
M
VP1
C1
Description:
Powerex Intellimod鈩?Intelligent
Power Modules are isolated base
modules designed for power
switching applications operating
at frequencies to 20kHz. Built-in
control circuits provide optimum
gate drive and protection for the
IGBT and free-wheel diode
power devices.
Features:
鈻?/div>
Complete Output Power
Circuit
VCC
FPO
SPR
CP1
VPC
GND
FO
TEMP
OUT1
SR
IN
OUT2
SENS
SINK
VN1
C2E1
鈻?/div>
Gate Drive Circuit
鈻?/div>
Protection Logic
鈥?Short Circuit
鈥?Over Current
鈥?Over Temperature
鈥?Under Voltage
Applications:
鈻?/div>
Inverters
鈻?/div>
UPS
鈻?/div>
Motion/Servo Control
鈻?/div>
Power Supplies
Ordering Information:
Example: Select the complete
part number from the table below
-i.e. PM300DSA120 is a 1200V,
300 Ampere Intellimod鈩?Intelligent
Power Module.
Type
PM
Current Rating
Amperes
300
V
CES
Volts (x 10)
120
VCC
FNO
SNR
CN1
VNC
GND
FO
TEMP
OUT1
SR
IN
OUT2
SENS
SINK
E2
Outline Drawing and Circuit Diagram
Dimensions
A
B
C
D
E
F
G
H
J
Inches
5.12
4.33鹵0.010
3.54
2.76鹵0.010
1.61
Millimeters
130.0
110.0鹵0.25
90.0
70.0鹵0.25
41.0
Dimensions
K
L
M
N
P
Q
R
S
T
Inches
0.71
0.57
0.53
0.51
M8 Metric
0.28
0.26 Dia.
0.100
0.08 Dia.
Millimeters
18.0
14.5
13.5
13.0
M8
7.0
Dia. 6.5
2.54
Dia. 2.0
1.34 +0.04/-0.02 34.0 +1/-0.5
1.22
1.10
1.06
31.0
28.0
27.0
665
