MITSUBISHI INTELLIGENT POWER MODULES
PM300DSA060
FLAT-BASE TYPE
INSULATED PACKAGE
N SIDE
1. VN1
2. SNR
3. CN1
4. VNC
5. FNO
P SIDE
1. VP1
2. SPR
3. CP1
4. VPC
5. FPO
A
B
G
G
J
N
T - DIA.
(2 TYP.)
12345
N
C2E1
E2
C1
S (8 TYP.)
H
D
C
123 45
P
Q - DIA.
(2 TYP.)
M
R - THD.
(3 TYP.)
0.64 MM SQ. PIN
(10 TYP.)
K
E
F
P
L
VP1
C1
Description:
Mitsubishi Intelligent Power Mod-
ules are isolated base modules de-
signed for power switching applica-
tions operating at frequencies to
20kHz. Built-in control circuits pro-
vide optimum gate drive and pro-
tection for the IGBT and free
wheel-diode power devices.
Features:
Complete Output Power
Circuit
VCC
FPO
SPR
CP1
VPC
FO
TEMP
OUT1
SR
IN
GND
OUT2
SENS
SINK
VN1
C2E1
Gate Drive Circuit
Protection Logic
鈥?Short Circuit
鈥?Over Current
鈥?Over Temperature
鈥?Under Voltage
VCC
FNO
SNR
CN1
VNC
FO
TEMP
OUT1
SR
IN
GND
OUT2
SENS
SINK
E2
Outline Drawing and Circuit Diagram
Dimensions
A
B
C
D
E
F
G
H
J
Inches
4.33
3.66鹵0.010
2.20
2.01
Millimeters
110.0
93.0鹵0.25
56.0
51.0
Dimensions
K
L
M
N
P
Q
R
S
T
Inches
0.55
0.51
0.47
0.33
0.28
0.22 Dia.
M5 Metric
0.100
0.08 Dia.
Millimeters
14.0
13.0
12.0
8.5
7.0
Dia. 5.5
M5
2.54
Dia. 2.0
Applications:
Inverters
UPS
Motion/Servo Control
Power Supplies
Ordering Information:
Example: Select the complete
part number from the table below
-i.e. PM300DSA060 is a 600V,
300 Ampere Intelligent Power Mod-
ule.
Type
PM
Current Rating
Amperes
300
V
CES
Volts (x 10)
60
1.14 +0.04/-0.02 29.0 +1/-0.5
1.02
0.98
0.90
0.85
26.0
25.0
23.0
21.5
Sep.1998
1
2
3
4
5
6
