Selectable feedback matching paths
Functional Block Diagram
CLKIN
MODE
REFCLK
1
Divide 2
0
Clock
Input
Matched
Delay
PFD
Charge
Pump
RCPLL
Clock
Tree
Matched
Delay
Divide 2
VCO
Differential
Ring Oscillator
CLKOUT
Figure 1. Functional Block Diagram
Pin Description
Pin Name
VDD
VSS
CLKIN
REFCLK
CLKOUT
MODE
RCPLL
3.3V
鹵
5% PLL Supply
0V PLL Ground
External Clock Input to PLL
Duty Cycle : 40%~60%
Feedback clock input to PLL from reference point on internal device clock tree
PLL output clock
Mode=1, select to REFCLK / Mode=0, select to Match Delay
Point of connection to external discrete loop filter
Description
