PLCD5584 Datasheet

  • PLCD5584

  • Low Power 0.145” 8-Character, 5x5 Dot Matrix Parallel Input...

  • 12頁

  • INFINEON   INFINEON

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

RED
PLCD5580
YELLOW
PLCD5581
HIGH EFFICIENCY RED
PLCD5582
GREEN
PLCD5583
HIGH EFFICIENCY GREEN
PLCD5584
Low Power 0.145鈥?8-Character, 5x5 Dot Matrix
Parallel Input Alphanumeric Intelligent Display
鈩?/div>
Package Dimensions in inches (mm)
1.680 (42.67) max.
0.210
(5.34)
0.105
(2.67)
0.771
(19.58)
0.386
(9.8)
Pin 1 Indicator
Part Number
EIA Date
Code
PLCD558X
SIEMENS WW
0.189
(4.79)
0.018 typ.
(.46)
Z
1
0.160鹵.020
(4.06鹵.50)
0.012 (0.30) typ.
Intensity Code
Color Bin
(For Yellow Only)
0.209 (5.31)
0.086
(2.19)
0.145
(3.68)
0.600
(15.24)
FEATURES
鈥?/div>
Eight 0.145鈥?(3.68 mm) High 5 x 5 Dot Matrix Char-
acters in Red, Yellow, High Ef鏗乧iency Red, Green,
or High Ef鏗乧iency Green
鈥?/div>
Built-in 2 Page, 256 Character ROM. Both Pages
Mask Programmable for Custom Fonts
鈥?/div>
Built-in Decoders, Multiplexers and Drivers
鈥?/div>
Wide Viewing Angle, X Axis
鹵
50
擄
, Y Axis
鹵
65
擄
鈥?/div>
Programmable Features:
鈥?Individual Flashing Character
鈥?Full Display Blinking
鈥?Multi-Level Dimming and Blanking
鈥?Clear Function
鈥?Lamp Test
鈥?/div>
Internal or External Clock
鈥?/div>
End Stackable Dual-In-Line Plastic Package
鈥?/div>
Low Power: 20% Less Power Consumption Than
5 X 7 Format
0.100
(2.54) typ.
DESCRIPTION
The PLCD5580 (Red), PLCD5581 (Yellow), PLCD5582 (High Ef鏗?
ciency Red), PLCD5583 (Green), and PLCD5584 (High Ef鏗乧iency
Green) are eight digit, 5x5 dot matrix, alphanumeric Programma-
ble Displays. The 0.145 inch high digits are packaged in a rug-
ged, high quality, optically transparent, standard 0.6 inch 28 pin
plastic DIP.
The on-board CMOS has a built-in two page, 256 character ROM.
Both pages are mask programmable for 256 custom characters.
The 鏗乺st page of ROM of the standard product contains 128 char-
acters including ASCII, selected European and Scienti鏗乧 sym-
bols. The second page contains Katakana Japanese characters,
more European characters, Avionics, and other graphic symbols.
The PLCD558X is designed for standard microprocessor inter-
face techniques and is fully TTL compatible. The Clock I/O and
Clock Select pins allow the user to synchronize multiple display
modules.
2鈥?31
