CRYSTAL CLOCK OSCILLATORS
Differential Positive ECL (DPECL)
Fast Edge
Data Sheet 0237A
Rev. -
PJ-A2960 Series
PRELIMINARY
Description
The
PJ-A2960 Series
of quartz crystal oscillators provide DPECL Fast Edge compatible signals. Systems
designers may now specify space-saving, cost-effective packaged PECL oscillators to meet their timing
requirements.
Features
鈥?Wide frequency range鈥?25.0MHz to 312.5MHz
鈥?User specified tolerance available
鈥?Will withstand vapor phase temperatures of 253擄C
for 4 minutes maximum
鈥?Space-saving alternative to discrete component
oscillators
鈥?High shock resistance, to 1000g
鈥?3.3 volt operation
鈥?Metal lid electrically connected to ground to
reduce EMI
鈥?Fast rise and fall times <600 ps
Electrical Connection
Pin
1
2
3
4
5
6
Connection
Enable/Disable
N.C.
V
EE
/Ground
Output
/Output
V
CC
鈥?High Reliability - NEL HALT/HASS qualified for
crystal oscillator start-up conditions
鈥?Low Jitter - Wavecrest jitter characterization
available
鈥?Overtone technology
鈥?High Q Crystal actively tuned oscillator circuit
鈥?Power supply decoupling internal
鈥?No internal PLL avoids cascading PLL problems
鈥?High frequencies due to proprietary design
鈥?Gold plated pads
