PEMD3; PIMD3; PUMD3

NPN/PNP resistor-equipped transistors;

R1 = 10 k鈩? R2 = 10 k鈩?/div>

Rev. 09 鈥?18 May 2005

Product data sheet

1. Product pro鏗乴e

1.1 General description

NPN/PNP Resistor-Equipped Transistors (RET).

Table 1:

Product overview

Package

Philips

PEMD3

PIMD3

PUMD3

SOT666

SOT457

SOT363

JEITA

SC-74

SC-88

PNP/PNP

complement

PEMB11

PUMB11

NPN/NPN

complement

PEMH11

PUMH11

Type number

1.2 Features

Built-in bias resistors

Simpli鏗乪s circuit design

Reduces component count

Reduces pick and place costs

1.3 Applications

Low current peripheral driver

Control of IC inputs

Replaces general-purpose transistors in digital applications

1.4 Quick reference data

Table 2:

Symbol

CEO

R2/R1

Quick reference data

Parameter

collector-emitter voltage

output current (DC)

bias resistor 1 (input)

bias resistor ratio

Conditions

open base

Min

0.8

Typ

Max

100

1.2

Unit

k鈩?/div>
