High current sink/source 25 mA/25 mA
Up to four external interrupts
Four 8-bit/16-bit Timer/Counter modules
Three Capture/Compare/PWM (CCP) modules:
- Capture is 16-bit, max. resolution 6.25 ns (T
CY
/16)
- Compare is 16-bit, max. resolution 100 ns (T
CY
)
- PWM output: PWM resolution is up to 10-bit
Master Synchronous Serial Port (MSSP) module
with two modes of operation:
- 3-wire SPI鈩?(supports all 4 SPI modes)
- I
2
C鈩?Master and Slave mode
One Addressable USART module
One Enhanced Addressable USART module:
- Supports LIN 1.2
- Auto-wake-up on Start bit
- Auto-baud detect
10-bit, up to 12-channel A/D Converter:
- Auto-acquisition
- Conversion available during Sleep
Two analog comparators
Programmable reference voltage for comparators
1000 erase/write cycle Flash program memory typical
Flash retention 100 years typical
Priority levels for interrupts
8 x 8 Single Cycle Hardware Multiplier
Power-on Reset (POR), Power-up Timer (PWRT)
and Oscillator Start-up Timer (OST)
Programmable Brown-out Reset (BOR)
Programmable 16-level Low-Voltage Detection
(LVD) module
Extended Watchdog Timer (WDT):
- Programmable period from 4 ms to 131s
In-Circuit Serial Programming鈩?(ICSP鈩? via two pins
In-Circuit Debug via two pins
Wide operating voltage range: 2.0V to 5.5V
鈥?/div>
鈥?/div>
鈥?/div>
Flexible Oscillator Structure:
鈥?Four Crystal modes:
- LP: up to 200 kHz
- XT: up to 4 MHz
- HS: up to 40 MHz
- HSPLL: 4-10 MHz (16-40 MHz internal)
鈥?Two External Clock modes, up to 40 MHz
鈥?Two External RC modes, up to 4 MHz
鈥?Internal Oscillator block:
- 8 user selectable frequencies: 31.25 kHz,
125 kHz, 250 kHz, 500 kHz, 1 MHz, 2 MHz,
4 MHz or 8 MHz
- 4x PLL option generates 16 MHz or 32 MHz
- Two modes select one or two I/O pins
- OSCTUNE 鈥?Allows user to shift frequency
鈥?Secondary Oscillator using Timer1 @ 32 kHz
鈥?Fail-Safe Clock Monitor:
- Allows for safe shutdown of device if primary or
secondary oscillator/clock fails
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Special Microcontroller Features:
External Memory Interface
(PIC18F8410 Devices only):
鈥?Address capability of up to 2 Mbytes
鈥?16-bit/8-bit interface
MSSP (SPI/
Master I
2
C)
10-bit A/D
(channels)
Device
Bytes
PIC18F6410
PIC18F8410
16K/0
16K/2M
# Single Word
Instructions
8192/0
8192/1M
Data
Memory
(bytes)
768
768
I/O
54
70
12
12
2
2
3
3
Y
Y
1/1
1/1
錚?/div>
2003 Microchip Technology Inc.
Advance Information
DS39619A-page 1
Timers
8-bit/16-bit
1/3
1/3
EUSART/
AUSART
CCP
Program Memory
(On-board/External)
Comparators
