PIC16LC74B-16/PTL16

8-Bit CMOS Microcontrollers with A/D Converter

RC6/TX/CK

RC5/SDO

RC4/SDI/SDA

RD3/PSP3

RD2/PSP2

RD1/PSP1

RD0/PSP0

RC3/SCK/SCL

RC2/CCP1

RC1/T1OSI/CCP2

PIC16LC74B-16/PTL16 Microcontroller Core

Features:

鈥?High-performance RISC CPU

鈥?Specially tested

- 16MHz @ 3V

鈥?Only 35 single word instructions to learn

鈥?All single cycle instructions except for program

branches which are two cycle

鈥?Operating speed: DC - 16 MHz clock input

DC - 250 ns instruction cycle

鈥?4K x 14 words of Program Memory,

192 x 8 bytes of Data Memory (RAM)

鈥?Interrupt capability

鈥?Eight level deep hardware stack

鈥?Direct, indirect and relative addressing modes

鈥?Power-on Reset (POR)

鈥?Power-up Timer (PWRT) and Oscillator Start-up

Timer (OST)

鈥?Watchdog Timer (WDT) with its own on-chip RC

oscillator for reliable operation

鈥?Programmable code-protection

鈥?Power saving SLEEP mode

鈥?Selectable oscillator options

鈥?Low-power, high-speed CMOS EPROM

technology

鈥?Wide operating voltage range: 2.5V to 5.5V

鈥?High Sink/Source Current 25/25 mA

鈥?Commercial, Industrial and Automotive

temperature ranges

鈥?Low-power consumption:

- < 5 mA @ 5V, 4 MHz

- 23

碌A(chǔ)

typical @ 3V, 32 kHz

- < 3

碌A(chǔ)

typical standby current

Pin Diagram:

TQFP

Peripheral Features:

鈥?Timer0: 8-bit timer/counter with 8-bit prescaler

鈥?Timer1: 16-bit timer/counter with prescaler

can be incremented during sleep via external

crystal/clock

鈥?Timer2: 8-bit timer/counter with 8-bit period

鈥?Capture, Compare, PWM module(s)

- Capture is 16 bit, max. resolution is 15.6 ns

- Compare is 16 bit, max. resolution is 250 ns

- PWM max. resolution is 10 bit

鈥?8-bit multichannel analog-to-digital converter

鈥?Synchronous Serial Port (SSP) with SPI

鈩?/div>

and I

鈩?/div>

鈥?Universal Synchronous Asynchronous Receiver

Transmitter (USART/SCI)

鈥?Parallel Slave Port (PSP), 8-bits wide, with

external RD, WR and CS controls

鈥?Brown-out detection circuitry for Brown-out Reset

(BOR) Pin Diagrams

漏

1999 Microchip Technology Inc.

Preliminary

RB4

RB5

RB6

RB7

MCLR/V

RA0/AN0

RA1/AN1

RA2/AN2

RA3/AN3/V

REF

RC7/RX/DT

RD4/PSP4

RD5/PSP5

RD6/PSP6

RD7/PSP7

RB0/INT

RB1

RB2

RB3

PIC16LC74B-16/PTL16

RC0/T1OSO/T1CKI

OSC2/CLKOUT

OSC1/CLKIN

RE2/CS/AN7

RE1/WR/AN6

RE0/RD/AN5

RA5/SS/AN4

RA4/T0CKI

DS30026A-page 1
