PI74FCT163373
3.3V 16-BIT TRANSPARENT LATCH
PI74FCT163373
Fast CMOS 3.3V 16-Bit
Transparent Latch
Product Features
鈥?Advanced Low Power CMOS Operation
鈥?Can serve as a 5V to 3V translator
鈥?Excellent output drive capability:
Balanced drives (24mA sink and source)
Compatible with LVC
TM
class of products.
鈥?Pin compatible with industry standard
double-density pinouts
鈥?Low ground bounce outputs
鈥?Hysteresis on all inputs
鈥?Industrial operating temperature range: 鈥?0擄C to +85擄C
鈥?Inputs can be driven by 3.3V or 5V devices
鈥?Multiple center pin and distributed Vcc/GND pins
minimizing switching noise
鈥?Packages available:
鈥?48-pin 240 mil wide plastic TSSOP (A)
鈥?48-pin 300 mil wide plastic SSOP (V)
鈥?48-pin 173 mil wide plastic TVSOP (K)
鈥?Device models available on request
Product Description
Pericom Semiconductor鈥檚 PI74FCT series of logic circuits are
produced in the Company鈥檚 advanced 0.6 micron CMOS
technology, achieving industry leading speed grades.
The PI74FCT163373 is a 16-bit transparent latch designed with
3-state outputs and are intended for bus oriented applications. The
Output Enable and Latch Enable controls are organized to operate
as two 8-bit latches or one 16-bit latch. When Latch Enable (LE)
is HIGH, the flip-flops appear transparent to the data. The data that
meets the set-up time when LE is LOW is latched. When OE is
HIGH, the bus output is in the high impedance state.
Logic Block Diagram
1
OE
2
OE
1
LE
2
LE
1
D
0
D
1
O
0
2
D
0
D
2
O
0
C
C
TO 7 OTHER CHANNELS
TO 7 OTHER CHANNELS
1
PS2055B
01/18/99
