PI74ALVC162334
16-Bit Universal Bus Driver
with 3-State Outputs
Product Features
鈥?PI74ALVC162334 is designed for low voltage operation,
V
CC
= 2.3V to 3.6V
鈥?Outputs have equivalent 26 ohm series resistors
鈥?Supports PC100 Registered DIMM
鈥?Typical V
OLP
(Output Ground Bounce) < 0.8V
at V
CC
= 3.3V, T
A
= 25擄C
鈥?Typical V
OHV
(Output V
OH
Undershoot) < 2.0V
at V
CC
= 3.3V, T
A
= 25擄C
鈥?Industrial operation at 鈥?0擄C to +85擄C
鈥?Packages available:
鈥?48-pin 240 mil wide plastic TSSOP (A48)
鈥?48-pin 173 mil wide plastic TVSOP (K48)
鈥?48-pin 300 mil wide plastic SSOP (V48)
Product Description
Pericom Semiconductor鈥檚 PI74ALVC series of logic circuits
are produced in the Company鈥檚 advanced 0.5 micron CMOS
technology, achieving industry leading speed.
The 16-bit PI74ALVC162334 universal bus driver is designed
for 2.3V to 3.6V Vcc operation.
Data flow from A to Y is controlled by Output Enable (OE).
The device operates in the transparent mode when LE is LOW.
When LE is HIGH, the A data is latched if CLK is held at a high
or low logic level. If LE is HIGH, the A-data is stored in the
latch/flip-flop on the low-to-high transition of CLK. When OE is
HIGH, the outputs are in the high-impedance state.
The outputs have equivalent 26 ohm series resistors to reduce
overshoot and undershoot.
To ensure the high-impedance state during power up or power
down, OE should be tied to Vcc through a pullup resistor; the
minimum value of the resistor is determined by the current-
sinking capability of the driver.
Logic Block Diagram
1
PS8313
08/04/98
1
2
3
4
5
