PI5C3307 Datasheet

  • PI5C3307

  • Digital Switch | 2-Bit Bus Switch w/Individual High Enables

  • 220.04KB

  • 3頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

21098765432121098765432109876543210987654321210987654321098765432109876543212109876543210987654321098765432121098765432109876543210987654321
21098765432121098765432109876543210987654321210987654321098765432109876543212109876543210987654321098765432121098765432109876543210987654321
PI5C3307
2-Bit Bus Switch with
Active High Enable
Product Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Near zero propagation delay
5鈩?switches connect inputs to outputs
Direct bus connection when switches are ON
Ultra Low Quiescent Power (0.2碌A(chǔ) typical)
鈥?Ideally suited for notebook applications
鈥?/div>
Packages available:
鈥?8-pin plastic SOIC (W)
Product Description
Pericom Semiconductor聮s PI5C series of logic circuits are produced
using the Company聮s advanced sub-micron CMOS technology,
achieving industry leading speed grades.
The PI5C3307 is a 2-bit digital switch designed with a fast enable.
When enabled via the associated Bus Enable (BE) pin, the 聯A聰 pin
is directly connected to the 聯B聰 pin. The bus switch introduces no
additional propagation delay or additional ground bounce noise.
The PI5C3307 device has an active HIGH enable.
PI5C3307 Logic Block Diagram
Product Pin Configuration
8-Pin
W
Truth Table
(1)
BE
L
H
A
Hi-Z
B
B
Hi-Z
A
Vcc
Vcc
Vcc
Function
Disconnect
Connect
Product Pin Description
Pin Name
BE
2
- BE
1
A
2
- A
1
B
2
- B
1
Vcc
GND
Description
Switch Enable
Bus A
Bus B
Power
Ground
Notes:
1. H = High Voltage Level, L = Low Voltage Level
Hi-Z = High Impedance, X = Don鈥檛 Care
1
PS8333D
02/17/99
