PI5C3306CD Datasheet

  • PI5C3306CD

  • Digital Switch | 2-Bit Bus Switch w/dual side undershoot pro...

  • 4頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

21098765432121098765432109876543210987654321210987654321098765432109876543212109876543210987654321098765432121098765432109876543210987654321
21098765432121098765432109876543210987654321210987654321098765432109876543212109876543210987654321098765432121098765432109876543210987654321
21098765432121098765432109876543210987654321210987654321098765432109876543212109876543210987654321098765432121098765432109876543210987654321
PI5C3306CD
2-Bit Bus Switch with Dual Side
Undershoot Protection
Product Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
R
ON
is 5-ohms typical
Undershoot protection up to 鈥?V (data inputs only)
Industrial Operation Temperature: 鈥?0擄C to +85擄C
Near zero propagation delay
Packages available:
鈥?8-pin 173 mil wide plastic TSSOP (L)
鈥?8-pin 118 mil wide plastic MSOP (U)
Product Description
Pericom Semiconductor鈥檚 PI5C series of logic circuits are produced
using the Company鈥檚 advanced submicron CMOS technology,
achieving industry leading performance.
The PI5C3306CD is a 5V, 2-bit Dual Side bus switch. It is intended
for PCI Hot-Plug applications. Industry leading advantages include
a propagation delay of 250ps that result from its 5-ohm channel
resistance and low I/O capacitance. The A-ports switch data to B
outputs and are bidirectional. The PI5C3306CD device has active
LOW enables.
When the switch is disabled, the A&B ports can handle up to 鈥?V
undershoot.
Applications
鈥?PCI Hot Plugging for live insertion
鈥?Memory bank sharing
Logic Block Diagram
Product Pin Configuration
A1
BE1
A2
BE2
B1
BE1
A1
B1
GND
1
2
3
4
8
7
6
5
Vcc
BE2
B2
A2
B2
8-Pin
L, U
Product Pin Description
Pin Name
BEn
A2- A1
B2- B1
V
CC
GND
Bus A
Bus B
Power
Ground
De s cription
Switch Enable
Truth Table
(1)
BEn
X*
H
L
An
Hi- Z
Hi- Z
Bn
Bn
Hi- Z
Hi- Z
An
Vcc
GND
VCC
VCC
Function
Disconnect
Disconnect
Connect
Notes:
1. H = High Voltage Level
L = Low Voltage Level
Hi-Z = High Impedance
X = Don鈥檛 Care
*A pull-up resistor should be provided for power-up protection.
1
PS8523A
08/27/02
