PI5C16862CB Datasheet

  • PI5C16862CB

  • Bus Switch

  • 288.23KB

  • 3頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

21098765432121098765432109876543210987654321210987654321098765432109876543212109876543210987654321098765432121098765432109876543210987654321
21098765432121098765432109876543210987654321210987654321098765432109876543212109876543210987654321098765432121098765432109876543210987654321
PI5C16862C
20-Bit, 2-Port Bus Switch
with Undershoot Protection
Product Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Near-zero propagation delay
5ohm switches connect inputs to outputs
Undershoot Protection up to 聳1V
Direct bus connection when switches are ON
32X384 function with flow through pinout make board
layout easier
鈥?/div>
Ultra-low quiescent power (120碌A(chǔ) typical)
聴 ideally suited for notebook applications
鈥?/div>
Industrial operating temperature: 聳40擄C to +85擄C
鈥?/div>
Packages available:
聴 48-pin 240-mil wide plastic TSSOP (A)
聴 48-pin 150-mil wide plastic BQSOP (B)
Product Description
Pericom Semiconductor聮s PI5C series of Bus Switch circuits are
produced using the Company聮s advanced submicron CMOS
technology, achieving industry leading speed.
The PI5C16862C is configured as a 20-bit, 2-port bus switch
designed with a low ON resistance (5ohm) allowing inputs to be
connected directly to outputs. The bus switch creates no additional
propagational delay or additional ground bounce noise. The
switches are turned ON by the Bus Enable (BEx) input signal.
The PI5C16862C can withstand undershoot of up to 聳1V.
Logic Block Diagram
Product Pin Configuration
48-Pin
A,B
Truth Table
(1)
Function
Disconnect
Connect
BE
X
A
19-A0
H
Hi-Z
L
B
19-B0
Product Pin Description
Pin Name
BEx
A
19-A0
B
19-B0
1
Note:
1. H = High Voltage Level
L = Low Voltage Level
Hi-Z = High Impedance
Description
Bus Enable Inputs (Active LOW)
Bus A
Bus B
PS8391A
06/10/99
