鈥?/div>
Minimizes Distortion and Error Voltages
On-Resistance Matching Channels, 0.8-ohm typ
On-Resistance Flatness, 3-ohm typ
Low Charge Injection Reduces Glitch Errors. Q = 4pC typ
Replaces Mechanical Relays
High Speed. t
ON
= 10ns typ
Low Off-Isolation: -72dB@1MHz
Wide -3dB Bandwidth: 170 MHz
High-Current Channel Capability: >100mA
TTL/CMOS Logic Compatible
Low Power Consumption (0.5碌W typ)
Pin-compatible with DG41X, MAX31X
The PI5A317A/381A/319A are analog switches designed for single-
supply operation. These high-precision device is ideal for low-
distortion audio, video, signal switching and routing.
The PI5A317A is a single-pole single-throw (SPST), normally
closed (NC) switch. The PI5A318A has the same pinout but is a
single-pole, single-throw (SPST, normally open (NO) function. The
PI5A319A is a single-pole, double-throw (SPDT) switch
Each switch conducts current equally well in either direction when
on. When off, they block voltages up toV
CC
.
The PI5A317A/381A/319A are fully specified with +5V and +3.3V
supplies. With +5V, they guarantee <18-ohm On-Resistance.
On-Resistance matching between channels is within 2-ohm.
On-Resistance flatness is less than 5-ohm over the specified range.
This switch family also guarantees fast switching speeds (t
ON
< 20ns).
These products are available in a 8-pin narrow body SOIC package
for operation over the industrial (-40
o
C to +85
o
C) temperature range.
Applications
鈥?/div>
Audio, Video Switching and Routing
鈥?/div>
Battery-Powered Communication Systems
鈥?/div>
Computer Peripherals
鈥?/div>
Telecommunications
鈥?/div>
Portable Instrumentation
Functional Diagram, Pin Configuration and Truth Table
COM 1
NC 2
GND 3
Vcc 4
8 NO
7 NIC
6 IN
PI5A319A 5 NIC
COM 1
NIC 2
GND 3
Vcc 4 PI5A317A
PI5A318A
IN
0
1
PI5A317A
ON
O FF
8 NC (NO, 318)
7 NIC
6 IN
5 NIC
PI5A318A
O FF
ON
IN
0
1
SW1
ON
O FF
SW2
O FF
ON
Switches shown for Logic 鈥?鈥?input
NC = Normally Closed, NO = Normally Open, NIC = Not Internally Connected
For free samples and the latest data sheet visit: www.pericom.com, or phone 1 800-435-2336
1
PS7059F
0210/03
