PI3V331
3.3V, Low ON Resistance Wideband/
Video Dual 4-Channel Mux/Demux
Product Features
聲 High-performance, low-cost solution to switch between
video sources
聲 Wide bandwidth: 134 MHz
聲 Low ON-resistance: 8 Ohms
聲 Low crosstalk at 10 MHz: 聳90dB
聲 Ultra-low quiescent power (0.1碌A(chǔ) typical)
聲 Single supply operation: +3.3V 鹵5%
聲 Fast switching: 5ns
聲 High-current output: 100mA
聲 Package:
聳 16-pin 150-mil-wide plastic QSOP (Q16)
Product Description
Pericom Semiconductor聮s PI3V series of mixed signal video
circuits are produced using the Company聮s advanced CMOS low
power technology achieving industry leading performance.
The PI3V331 is a true bidirectional Dual 4-channel multiplexer/
demultiplexer that is recommended for both S-Video or composite
video switching applications. The VideoSwitch聶 can be driven
from a current output RAMDAC or voltage output composite
video source.
Low ON-resistance and wide bandwidth make it ideal for video
and other applications. Also this device has exceptionally high
current capability which is far greater than most analog switches
offered today. A single 3.3V supply is all that is required for
operation.
The PI3V331 offers a high-performance, low-cost solution to
switch between video sources.
Truth Table
ENA
1
X
0
0
0
0
ENB
X
1
0
0
0
0
IN1
X
X
0
0
1
1
IN0
X
X
0
1
0
1
ON SWITCH
Disable A
Disable B
S1A- DA, S1B- DB
S2A- DA, S2B- DB
S3A- DA, S3B- DB
S4A- DA, S4B- DB
16-Pin Product Configuration
EN
A
IN
1
S4
A
S3
A
S2
A
S1
A
D
A
GND
1
2
3
4
5
6
7
8
16
15
14
16-Pin
W,Q
13
12
11
10
9
V
CC
EN
B
IN
0
S4
B
S3
B
S2
B
S1
B
D
B
Functional Block Diagram
S1
A
S2
A
S3
A
S4
A
S1
B
S2
B
S3
B
S4
B
D
B
D
A
Product Pin Description
Pin Name
S1
A
, S2
A
S3
A
, S4
A
S1
B
, S2
B
S3
B
, S4
B
S
0
, S
1
EN
A,
EN
B
D
A
, D
B
GND
V
CC
Description
Analog Video I/O
(Usually Inputs)
Select Input
Enable
Analog Video I/O
(Usually Outputs)
Ground
Power
DECODER
EN
A
EN
B
IN
1
IN
0
1
PS8509
