PI3DBV10
3.3V, Wide Bandwidth, 1-Channel, 2:1 Mux/
Demux Video Switch w/ Single Enable
Product Features
鈥?/div>
R
ON
is 4鈩?typical
鈥?Low bit-to-bit skew: 200ps
鈥?Low Crosstalk: 鈥?7dB @ 250MHz
鈥?Near-Zero propagation delay: 250ps
鈥?Switching speed: 9ns
鈥?Channel On Capacitance: 9pF (typical)
鈥?V
CC
Operating Range: +3.0V to +3.6V
鈥?ESD>2000V . . . Human Body Model
鈥?>500 MHz bandwidth (or data frequency)
鈥?Package (Pb-free available):
-12-contact TDFN (ZE)
Product Description
Pericom Semiconductor鈥檚 PI3DBV series of logic circuits are
produced using the Company鈥檚 advanced sub-micron CMOS
technology, achieving industry leading performance.
The PI3DBV10 is a 2- to 1-Channel multiplexer/demultiplexer
Video Switch with Hi-Z outputs. Industry leading advantages
include a propagation delay of less than 250ps, resulting from
its low channel resistance and I/O capacitance. The device
multiplexes differential outputs from a video source to one of
two corresponding outputs, or switch two inputs to a common
display. The switch is bidirectional and offers little or no attenu-
ation of the high-speed signals at the outputs. It is designed for
low bit-to-bit skew, high channel-to-channel noise isolation and
is compatible with various standards, such as LVDS and TMDS.
Application
鈥?Routes physical layer signals for high bandwidth
digital video
Logic Block Diagram
Pin Description
GND
Y0
Y1
0I0
1I0
0I1
1I1
SEL
VDD
Y
0
Y
1
GND
SEL
1
2
3
4
5
6
12
11
10
9
8
7
0l0
1I0
0I1
1I1
VDD
GND
Truth Table
Function
Y
n
to
n
I
o
Y
n
to
n
I
1
SEL
L
H
1
PS8707
12/05/03
