PI3C16861
Product Features
聲
聲
聲
聲
聲
聲
聲
聲
聲
Near-zero propagation delay
5-Ohm switches connect inputs to outputs
High Bandwidth (>400 MHz)
Rail-to-Rail 3.3V or 2.5V switching
Permits Hot Insertion
High Bandwidth data switching
Hot Docking
2.5V Supply Voltage Operation
Packages available:
聳 48-pin 240-mil wide plastic TSSOP (A)
聳 48-pin 150-mil wide plastic BQSOP (B)
聳 48-pin 300-mil wide plastic SSOP (V)
Product Description
2.5V/3.3V, High Bandwidth, Hot Insertion,
20-Bit, 2-Port BusSwitch
Pericom Semiconductor聮s PI3C series of Bus Switch circuits are
produced using the Company聮s advanced submicron CMOS
technology, achieving industry leading speed.
The PI3C16861 is configured as a 2.5V or 3.3 volt, hot insertion, 20-
bit, 2-port bus switch designed with a low ON resistance (5 Ohm)
allowing inputs to be connected directly to outputs. The bus switch
creates no additional propagational delay or additional ground
bounce noise. The switch is turned ON by the Bus Enable (BE) input
signal. The device is 5V I/O Tolerant.
This device is very useful in switching signals that have high
bandwidth (>400 MHz) requirements.
Logic Block Diagram
Product Pin Configuration
48 Pin
A, B, V
Truth Table
(1)
Function
Disconnect
Connect
Note:
1. H = High Voltage Level
L = Low Voltage Level
Hi-Z = High Impedance
BE
X
H
L
A19 - A0
Hi- Z
B19 - B0
Product Pin Description
Pin Name
BEx
A
19-A0
B
19-B0
1
Description
Bus Enable Inputs (Active LOW)
Bus A
Bus B
PS8424C
01/09/01
1
2
3
4
5
