PI3B33X257
3.3V, 24:12 Mux/Demux
NanoSwitch聶
Product Features
聲 Near-zero propagation delay
聲 5 ohm switches connect inputs to outputs
聲 Direct bus connection when switches are ON
聲 Ultra Low Quiescent Power (0.2碌A(chǔ) Typical)
聳 Ideally suited for notebook applications
聲 TTL - compatible control of input levels
聲 Fast switching speed - 4.5ns max.
聲 Package available: 48-pin 150-mil wide plastic BQSOP (B)
Product Description
Pericom Semiconductor聮s PI3B series of logic circuits are produced
using the Company聮s advanced submicron CMOS technology,
achieving industry leading performance.
The PI3B33X257 is a 3.3V, 24:12 multiplexer/demultiplexer with
three-state outputs. Inputs can be connected to outputs with low
on resistance (5 ohm) with no additional ground bounce noise or
propagation delay.
Pin Configuration
S0
IA0
IA1
YA
IB0
IB1
YB
GND
S1
IE0
IE1
YE
IF0
IF1
YF
GND
S2
II0
II1
YI
IJ0
IJ1
YJ
GND
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
48
47
46
45
44
43
42
41
40
VCC
E0
ID0
ID1
YD
IC0
IC1
YC
VCC
E1
IH0
IH1
YH
IG0
Logic Block Diagram
IA0
SW
SW
E0
SW
SW
SW
S0
SW
SW
SW
YA
IE0
SW
SW
E1
SW
SW
SW
S1
SW
SW
SW
YE
YF
II1
IJ0
IJ1
YG
IK0
IK1
YH
IL0
IL1
IE1
YB
IF0
YC
YD
IA1
IB0
IB1 IC0 IC1 ID0 ID1
IF1 IG0 IG1 IH0 IH1
48-Pin
B
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
IG1
YG
VCC
E2
IL0
IL1
YL
IK0
IK1
YK
OE
YI
YJ
YK
YL
S2
E2
II0
SW
SW
SW
SW
SW
SW
SW
SW
SW
A
B
1
PS8334C
02/26/02
1
2
3
4
