PI3A4629 Datasheet

  • PI3A4629

  • Analog | 3.0V. SOTiny. 0.4-Ohm SPST Analog Switch

  • 8頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

PI3A4629
3.0V, SOT
INY
鈩?/div>
Single-Supply
0.4鈩?SPST (NO) CMOS Analog Switch
Features
鈥?Low On-Resistance: 0.4鈩?Max (+2.7V Supply)
鈥?0.1鈩?Max. On-Resistance Flatness at +25擄C
鈥?Fast Switching: 10ns Max.
鈥?+1.5V to +3.6V Single-Supply Operation
鈥?TTL/CMOS-Logic Compatible
鈥?鈥?5dB Off-Isolation at 100KHz
鈥?1nA Max. Off-Leakage at +25擄C
鈥?Packaging (Pb-free available):
鈥?5-pin Small Compact SOT-23
鈥?6-contact Ultra Compact Thin Dual in-line Flat No Lead
TDFN
Description
PI3A4629 is a single-pole/single-throw (SPST) normally open
(NO) analog switch that operates from a single +1.5V to +3.6V
supply.
The switch has 0.4鈩?Max On-Resistance (R
ON
), with 0.1鈩?Max
R
ON
flatness over the analog signal range when powered from a
+3.0V supply. Leakage currents are less than 2nA and fast switch-
ing times are less than 10ns.
To minimize PC board area use, the device is available in the
ultra compact TDFN and the small compact SOT-23 packages.
The PI3A4629 pinout is optimized for the highest package off-
isolation available.
Applications
Functional Block Diagrams/Pin Configurations
Top Views
IN 1
5 V
CC
鈥?Cellular Phones 鈥?Communications Circuits
鈥?Battery-Operated Equipment 鈥?DSL Modems
鈥?Audio and Video Signal Routing 鈥?PCMCIA Cards
Pin Description
TDFN
2
4
3
1
6
5
SOT-23
2
4
3
1
5
-
Name
COM
NO
GND
IN
V
CC
N.C.
Function
Analog Switch, Common
Analog Switch, Normally
Open
Ground
Digital Control Input
Positive Supply Voltage
No Internal Connection
COM 2
GND 3
SOT23
4 NO
Note:
NO and COM pins are identical and interchangeable. Any pin may be
considered as an input or an output; signals pass.
IN 1
COM 2
GND 3
6 V
CC
5 N.C.
4 NO
Truth Table
Input
LOW
HIGH
Switch State
OFF
ON
TDFN
N.C. = No Internal Connection
Switches shown for Logic 鈥?鈥?input
1
PS8717
12/15/03
