PI3A4628
3.0V, SOT
INY
鈩?/div>
Single-Supply
0.4鈩?SPST (NO) CMOS Analog Switch
Features
鈥?Low On-Resistance: 0.4鈩?Max (+2.7V Supply)
鈥?0.1鈩?Max. On-Resistance Flatness at +25擄C
鈥?Fast Switching: 10ns Max.
鈥?+1.5 V to +3.6V Single-Supply Operation
鈥?TTL/CMOS-Logic Compatible
鈥?鈥?5dB Off-Isolation at 100KHz
鈥?1nA Max. Off-Leakage at +25擄C
鈥?Packaging (available Pb-free):
鈥?6-pin Small Compact SOT-23
鈥?6-contact Ultra Compact Thin Dual in-line Flat No Lead
TDFN
Description
PI3A4628 is a single-pole/single-throw (SPST) normally open
(NO) analog switch that operates from a single +1.5V to +3.6V
supply. The device has two control inputs.
The switch has 0.4鈩?Max On-Resistance (R
ON
), with 0.1鈩?Max
R
ON
flatness over the analog signal range when powered from a
+3.0V supply. Leakage currents are less than 2nA and fast switch-
ing times are less than 10ns.
To minimize PC board area use, the device is available in the ultra
compact TDFN and the small compact SOT-23 packages.
Functional Block Diagrams/Pin Configurations
Top View
COM 1
NO 2
6 V
CC
Applications
鈥?Cellular Phones 鈥?Communications Circuits
鈥?Battery-Operated Equipment 鈥?DSL Modems
鈥?Audio and Video Signal Routing 鈥?PCMCIA Cards
Pin Description
Pin Number
1
2
3
4
5
6
Name
COM
NO
GND
IN
IN
V
CC
Description
Analog Switch, Common
Analog Switch, Normally Open
Ground
Digital Control Input
Digital Control Input
Positive Supply Voltage
5 IN
4
IN
GND 3
Switches shown for Logic 鈥?鈥?input
Truth Table
IN
1
1
0
0
IN
0
1
0
1
Switch State
OFF
OFF
ON
ON
Note:
NO and COM pins are identical and interchangeable. Any pin may be
considered as an input or an output; signals pass.
1
PS8716
12/15/03
