鈥?/div>
Low On-Resistance: 0.4鈩?(+2.7V Supply)
R
ON
Matching: 0.1鈩?Max.at 25 擄C
R
ON
Flatness: 0.1鈩?Max. (+3.0V Supply) at 25 擄C
Low 2nA Input Leakage at 25 擄C
+1.5V to +3.6V Single-Supply Operation
Fast Switching Time: 30ns Max.
Make-Before-Break Switching Guaranteed
-41dB Off-Isolation at 100KHz
TTL/CMOS Logic Compatible
Low Power Consumption: 5碌W
Packages (Pb-free avaliable):
鈥?6-pin Small Compact SOT-23
鈥?6-pin Ultra Compact Thin Dual in-line Flat No Lead
(TDFN)
Description
The PI3A4625 is a single-pole, double-throw (SPDT) analog switch.
Improved specifications include a low On-Resistance of 0.4鈩? and
fast switching times (30ns Max.) with 3.0V supply operation.
Specifications are given for 1.8V, 2.5V and 3.3V power supply
operation. Operating voltage range is +1.5V to +3.6V.
To minimize PC board area use, the device is available in the ultra
compact TDFN, and the small compact SOT-23 6-pin packages.
Operating temperature range is 鈥?40擄C to 85擄C.
Functional Diagram, Pin Configuration
Applications
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Communication Circuits
Cellular Phones
Audio and Video Signal Routing
Portable Battery-Operated Equipment
Data Acquisition Systems
Computer Peripherals
Telecommunications
Relay Replacement
Wireless Terminals and Peripherals
Hard Drives
Modems
IN
1
6
NO
V
CC
2
5
COM
GND
3
4
NC
SOT23
Truth Table
Logic
0
1
NC
ON
OFF
NO
OFF
ON
V
CC
2
5
IN
1
6
NO
COM
GND
3
4
NC
TDFN
Switches shown for Logic 鈥?鈥?input
Top View
1
PS8713
12/15/03
