PHB95N03LTA

TrenchMOS鈩?logic level FET

Rev. 01 鈥?27 August 2002

M3D166

Product data

1. Description

N-channel logic level 鏗乪ld-effect power transistor in a plastic package using

TrenchMOS鈩?technology.

Product availability:

PHB95N03LTA in SOT404 (D

2

-PAK).

2. Features

s

Low on-state resistance

s

Fast switching.

3. Applications

s

High frequency computer motherboard DC to DC converters.

4. Pinning information

Table 1:

Pin

1

2

3

mb

Pinning - SOT404 simpli鏗乪d outline and symbol

Description

gate (g)

mb

Simpli鏗乪d outline

Symbol

drain (d)

source (s)

mounting base,

connected to

drain (d)

[1]

d

g

2

1

3

MBK116

MBB076

s

SOT404 (D

2

-PAK)

[1]

It is not possible to make connection to pin 2 of the SOT404 package.
