Electrical Specifications at 25擄C
Symbol
BV
CES
I
CES
R
TH(JC)
P
O
G
P
畏
R
L
VSWR-T
VSWR-S
Parameter
Collector-Emitter Breakdown
Collector-Emitter Leakage
Thermal Resistance
Output Power
Power Gain
Collector Efficiency
Input Return Loss
Load Mismatch Tolerance
Load Mismatch Stability
Test Conditions
I
C
=125mA
V
CE
=45 V
V
CC
=45 V, Pin=26 W, f=1090 MHz
V
CC
=45 V, Pin=26 W, f=1090 MHz
V
CC
=45 V, Pin=26 W, f=1090 MHz
V
CC
=45 V, Pin=26 W, f=1090 MHz
V
CC
=45 V, Pin=26 W, f=1090 MHz
V
CC
=45 V, Pin=26 W, f=1090 MHz
V
CC
=45 V, Pin=26 W, f=1090 MHz
Min
80
-
-
175
8.3
55
9
-
-
Max
-
12.5
0.4
-
-
-
-
2:1
1.5:1
Units
V
mA
擄C/W
W
dB
%
dB
-
-
V2.00
