Hermetic Metal/Ceramic Package
ABSOLUTE MAXIMUM RATINGS AT 25擄C
Parameter
Symbol
Rating
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current (Peak)
Total Power Dissipation
Storage Temperature
Junction Temperature
V
CES
V
EBO
I
C
P
D
T
STG
T
J
70
3.0
6
160
-65 to +200
200
Units
V
V
A
W
擄C
擄C
ELECTRICAL CHARACTERISTICS AT 25擄C
Parameter
Symbol
Min
Collector-Emitter Breakdown
Voltage
Collector-Emitter Leakage
Current
Thermal Resistance
Output Power
Power Gain
Collector Efficiency
Input Return Loss
Load Mismatch Tolerance
Load Mismatch Stability
BV
CES
I
CES
R
TH(JC)
P
OUT
G
P
70
-
-
75
9
45
8
-
-
Max
-
3.5
1.5
-
-
-
-
3:1
1.5:1
Units
V
mA
擄C/W
W
dB
%
dB
-
-
I
C
=35mA
V
CE
=40V
Test Conditions
V
CC
=45 V, P
out
=75 W, F=1.03 1.09 GHz
V
CC
=45 V, P
in
=9 W, F=1.03, 1.09 GHz
V
CC
=45 V, P
out
=75 W, F=1.03, 1.09 GHz
V
CC
=45 V, P
out
=75 W, F=1.03, 1.09 GHz
V
CC
=45 V, P
out
=75 W, F=1.03, 1.09 GHz
V
CC
=45 V, P
out
=75 W, F=1.03, 1.09 GHz
V
CC
=45 V, P
out
=75 W, F=1.03, 1.09 GHz
畏
C
RL
VSWR-T
VSWR-S
BROADBAND TEST FIXTURE IMPEDANCE
F (MHz)
Z
IF
(鈩?
Z
OF
(鈩?
1030
1090
2.6 - j6
2.3 - j5.6
9.4 + j2
11 + j0.2
M/A-COM POWER HYBRIDS OPERATION
路
1742 CRENSHAW BLVD
路
TORRANCE, CA 90501 (310) 320-6160
路
FAX (310) 618-9191
M/A-COM, PHO RESERVES THE RIGHT TO MAKE CHANGES AND IMPROVEMENTS WITHOUT NOTICE.
DS181 Rev 04/11/97
