Designed for Short Pulse IFF Applications
NPN Silicon Microwave Power Transistor
Common Base Configuration
Broadband Class C Operation
High Efficiency Interdigitated Geometry
Diffused Emitter Ballasting Resistors
Gold Metalization System
Internal Input and Output Impedance Matching
Hermetic Metal/Ceramic Package
Outline Drawing
1
Description
M/A-COM鈥檚 PH1090-550S is a silicon bipolar NPN transistor
intended for use in L-band, 1.2 - 1.4 GHz avionics equipment
such as IFF, mode-S and TCAS systems. Designed for
common-base, class C broadband pulsed power applications, the
PH1090-550S delivers 7.5 dB of gain at 550 watts of output
power when operating with short pulse length (10碌S), at 1
percent duty cycle. The transistor is housed in a 2-lead, rectan-
gular metal-ceramic flange package, with internal input and
output impedance matching networks. Diffused emitter ballast
resistors and gold metalization assure ruggedness and long-term
reliability.
Notes: (unless otherwise specified)
1. Tolerances are: inches 鹵 .005鈥?(millimeters 鹵 0.13mm)
Broadband Test Fixture Impedance
F (MHz)
1030
1090
Z
IF
(鈩?
4.0 - j3.5
3.6 - j2.7
Z
OF
(鈩?
1.4 - j1.6
1.1 - j1.9
Absolute Maximum Rating at 25擄C
Parameter
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current (Peak)
Total Power Dissipation
@ +25擄C
Storage Temperature
Junction Temperature
Symbol
V
CES
V
EBO
I
C
P
TOT
T
stg
T
j
Rating
80
3.0
28
1800
-65 to +200
200
Units
V
V
A
W
擄C
擄C
TEST FIXTURE
INPUT
CIRCUIT
TEST FIXTURE
OUTPUT
CIRCUIT
50
鈩?/div>
ZIF
ZOF
50
鈩?/div>
Electrical Specifications at 25擄C
Symbol
BV
CES
I
CES
R
TH(JC)
P
in
G
P
畏
R
L
VSWR-T
VSWR-S
Parameter
Collector-Emitter Breakdown
Collector-Emitter Leakage
Thermal Resistance
Input Power
Power Gain
Collector Efficiency
Input Return Loss
Load Mismatch Tolerance
Load Mismatch Stability
Test Conditions
I
C
=250mA
V
CE
=45 V
V
CC
=50 V, P
out
=550 W, f=1090 MHz
V
CC
=50 V, P
out
=550 W, f=1090 MHz
V
CC
=50 V, P
out
=550 W, f=1090 MHz
V
CC
=50 V, P
out
=550 W, f=1090 MHz
V
CC
=50 V, P
out
=550 W, f=1090 MHz
V
CC
=50 V, P
out
=550 W, f=1090 MHz
V
CC
=50 V, P
out
=550 W, f=1090 MHz
Min
80
-
-
-
7.5
55
9
-
-
Max
-
25
0.05
100
-
-
-
10:1
1.5:1
Units
V
mA
擄C/W
W
dB
%
dB
-
-
V2.00
M/A-COM Division of AMP Incorporated
3
North America: Tel. (800) 366-2266, Fax (800) 618-8883
3
Asia/Pacific: Tel.+85 2 2111 8088, Fax +85 2 2111 8087
3
Europe: Tel. +44 (1344) 869 595, Fax+44 (1344) 300 020
www.macom.com
AMP and Connecting at a Higher Level are trademarks.
Specifications subject to change without notice.
